Click on the image to view the original image
- Place of Origin:
- Guangdong, China
- Brand Name:
- WGP
- Model Number:
- UPS901A-10
- Phase:
- Single Phase
- Protection:
- Overcurrent
- Weight:
- 153G
- Output Voltage:
- 9V
- Type:
- On-line, on line 9V 1A mini ups
- Application:
- security,networking,telecommunication,minitoring,alarm
- Capacity:
- 16.28wh/2200mAh
- Size:
- 111x60x26mm
- Input:
- 9V 1A
- Output:
- 9V 1A
- Battery Type:
- Lithium Ion Battery
- Net Weight:
- ≤153g
- Backup time:
- 2~8hours
- Material:
- ABS
- Product name:
- price of online ups systems Shenzhen 9v dc battery backup
Packaging & Delivery
- Selling Units:
- Single item
- Single package size:
- 22X21X17 cm
- Single gross weight:
- 0.5 kg
- Package Type:
- 44PCS/CTN 8.9KG/CTN 42*23*24CM
- Picture Example:
![package-img]()
- Lead Time:
Quantity(Piece) 1 - 2 3 - 500 >500 Est. Time(days) 3 15 To be negotiated
price of online ups systems Shenzhen 9v dc battery backup
DC 9V Mini UPS Tecnical Features :
Mini UPS uninterruptible power supply is a standby energy storage power supply. Used safe and environmental lithium cells, credible and stable PCB, trickle/constant-current/ constant-voltage lithium battery charging BMS.
Created by high performance and efficiency DC-DC, boosting and switching circuit. This mini UPS with perfect over-charged, over-discharged, over-current and short-circuit protection.
| DC 9V Mini UPS Basic Information | |
| Model | UPS901A |
| Capacity | 16.28wh/2200mAh |
| Battery Type | 18650 lithium ion battery |
| Input Voltage | 9.2V ±5% |
| Input current | 350mA+loading current |
| Output Voltage | 9.2V±10% |
| Output current | ≤1000mA |
| Discharging transfer efficiency | ≥85% |
| Over-discharged protection(battery) | 6.0V( Over-discharged release 6.3V) |
| Over-charged protection(battery) | 8.5V( Over-charged release 8.25V) |
| With load current(battery) | ≥2000mA |
| Working temperature | -20°C~85°C |
| Weight | ≤153g |
| Size | 111x60x26mm |
| Warranty | 1 year |
| Certification | CE,ROHS,FCC,PSE |
| Packing Method | |
| 1. Well protection neutral box packing | |
| 2. 44PCS/CTN | |
| 3. CTN Size:42*23*24CM | |
| 4. G.W 11kg | |
| Packing Include | |
| UPS Battery | 1PC |
| DC Cable | 1PC |
| User Manual | 1PCS |
| Delivery Time | |
| Sample | 2-3 working days |
| Bulk Order | 15-20 working days |
| Shipping Method | |
| DHL,UPS,FedEX,EMS,HongKong Post,Swiss Post etc.... | |
Q:What"s the type of ups?
A:It"s a mini on-line ups.
Q:How is it work?
A:When have electricity,ups act as a bridge, city power provide electric to device,at the same time,ups is being charging.When no electricity,then ups back up the device.
Q:How to charge the UPS?
A:Battery will only charge with power switch in the ON position.
Q:What"s the backup time?How can i decide which model is suitable to my device?
A:Different capacity will have different backup time,with following information,we can choose the most suitable ups to you :
1.What"s the device you plan to use?
2.What"s the working voltage and current?
3.What"s your expected backup time?
Q:How can I maintain the device lifetime?
A:When stored, the ups will self-discharge at a rate that is greatly affected by the ambient temperature. It should therefore be fully charged before being put into storage and if it is to be stored for a long period, it should be recharged periodically to prevent it from losing its original capacity.
As a guide, the ups should not be stored for longer than the periods shown below without being recharged:
6 months at 20°C
3 months at 30°C
2 months at 35°C
If the ups was not used for long time, it is suggested to charge it once every 3~5months
Q:Do you have any other models?
A:Yes,we have variety models with defferent capacities,please contact with me for more details.
