The atgm336h-5n module is the general name of the small size and high-performance BDS/GNSS all-constellation positioning navigation module series.The module products are based on the fourth-generation low-power GNSS SOC single chip - AT6558, supporting a variety of satellite navigation systems, including BDS (beidou satellite navigation system) in China, GPS in the United States, GLONASS in Russia, GALILEO in the European Union, QZSS in Japan and SBAS (WAAS, EGNOS, GAGAN, MSAS).AT6558 is a real six-in-one multi-mode satellite navigation and positioning chip with 32 tracking channels. It can receive GNSS signals of six satellite navigation systems at the same time and realize joint positioning, navigation and timing.Atgm336h-5n this series of modules has the advantages of high sensitivity, low power consumption and low cost. It is suitable for vehicle-mounted navigation, handheld positioning and wearable devices, and can directly replace the MAX series modules.
Functions and features
LCM0802A character liquid crystal display module is a dot matrix liquid crystal display module specially used to display letters, Numbers, symbols, etc. It can display 2 lines, 8 characters per line, and supports 4-bit to 8-bit data transmission mode.Provide 5*7 dot matrix + cursor display mode, provide display data buffer DDRAM, character generator CGROM and character generator CGRAM, you can use CGRAM to store the submodule data of the graphic characters defined by yourself for up to 8 5*8 dot arrays.Rich instruction Settings are provided;Clear display;The cursor returns to the origin;Display on/off;Open/close the cursor;Display character flashing;Cursor shift;Display shift, etc.
Performance index
- Excellent positioning and navigation functions, single system positioning of BDS/GPS/GLONASS satellite navigation system, combined positioning of any combination of multiple systems, and support QZSS and SBAS systems
- Support A - GNSS
- Cold start capture sensitivity: -148dbm
- Tracking sensitivity: -162dbm
- Positioning accuracy: 2.5m (CEP50, open area)
- Initial positioning time: 32 seconds
- Low power consumption: continuous operation <25mA (@3.3v)
- Built-in antenna detection and short-circuit protection function
