- Place of Origin:
- Guangdong, China
- Brand Name:
- Sanforce
- Bulb Type:
- LED
- Battery Type:
- Ni-Cd
- Material:
- metal
- Usage:
- emergency lighting
- Certification:
- CE
- Specifications:
- LED LIGHTS
- Warranty(Year):
- 3-YEAR
- Product Name:
- emergency conversion kits
- Input Voltage:
- 220V-240V 50/60HZ
- Charge time:
- 24hrs
- Warranty:
- 3 Years
- Emergency Time:
- 3Hrs
- Emergency Power:
- 18W
- Output Voltage:
- DC220-310V
- inverter Size:
- 180*40*30mm
- Metal Case Size:
- integrated with LED lighting fixture
- Battery:
- Ni-cd Battery
- Supply Ability:
- 20000 Set/Sets per Month
- Packaging Details
- Inner box size:280*110*57mm
Outer box size:350*295*248mm
- Port
- Shenzhen or Hongkong
- Picture Example:
![package-img]()
- Lead Time:
Quantity(Sets) 1 - 200 201 - 500 501 - 1000 >1000 Est. Time(days) 14 18 22 To be negotiated
| Model No. | LMO103C018S |
| Product Name | LED emergency module |
| Battery Type | NiMH, NiCd |
| Lighting Power | 18W LED panel |
| Emergency Power | 18W |
| Input voltage | AC85~265V, 50/60Hz |
| Battery protection | Yes |
| Operation temperature | -20--70℃ , 65+20% RH |
| Highest Surface Temperature | 50°C |
| Battery Capacity | 12V 6000mAh Rechargeable Nicd battery pack |
| Charging Time | >24h without break |
| Output Voltage in emergency | DC220-310V |
| Suitable light source | LED tube |
| Emergency power | 100% |
| Emergency duration | 180 minutes |
| Product Weight | 2.5kgs |
| Inverter dimension | 180*40*30mm |
| Outer casing size | no need, put in LED tube housing |
| Note | Custom-Made battery to be configured with different back-up period and different light output levels. |
Description
20W Tube light led emergency kits built in power pack is full emergency output module. To be installed inside of led tube housing for more convenient and easy usage.
The converter automatically adjusts the output LED current and keeps Fixed Voltage output to provide the best match between the battery and the load, providing maximum illumination whilst ensuring full battery duration.
The product range to cover a variety of LED fixture ideal for high voltage board(220-310V DC)LED tube, Led Sensor tube and Tri-proof tube...etc with internal LED driver.
Features
- IC controlled Dual rate Charger for energy savings.
- Short circuit protection at battery terminals.
- Battery reverse protection functionality
- Charge indicator and test button. The light fittings guarantee safety of people in buildings open to the general public.
- Automatically actuated in the event of power cuts, these devices (kit + light fitting) offer a good luminous flux to facilitate the evacuation.
- Comply with European standards EN 61 347-2-7 and offer a high level of quality and safety meeting the various prevailing regulations.
- 100% emergency power output ,Dial the code to suitable current of luminaires.
Sanforce is a manufacturer specializing in emergency conversion kits for LED and fluorescent lighting since 2008.
We cooperate with valuable supply chain, inspect all the incoming materials and set up strict product assurance system, such as SMT, Auto Aging test, Simulation test during our production process. We have very skillful and responsible workers, most of them have been working here over 6 years.
With strong technical support and customer- oriented service, you can be sure that Sanforce is ready to support you, whatever your needs.
1.What is your main product line is made?
We are dedicating to LED emergency power pack for commercial lighting, research,
manufacturing and sales, aiming to be a leading emergency lighting backup power producer.
Our main products include:1). Constant current output of Led conversion kit for LED panel
light, LED down lights and other LED light applications with external driver. Emergency
output power differed from 5-90% according to customer’s requirement.
2). 100% emergency output power of emergency kits for LED tube with AC220V or DC110-150V
output.
3). Emergency lighting battery packs for Fluorescent tube 14-98W.
4). High Temperature rechargeable NiCD and NiMH battery pack for emergency control gear
5). Emergency LED T8 tube and min LED T5 3W-4W
6) Constant power emergency kits.
2.You have the ability to do independent research and development?
Our engineering department has 3-5 people, we have the research and development
capabilities. We also collect each customer’s feedback regularly, We have the ability on
product improvement and new product development.
