- Place of Origin:
- Guangdong, China
- Brand Name:
- Sanforce or OEM
- Bulb Type:
- LED
- Battery Type:
- Ni-Cd
- Material:
- ABS plastics orsteel plate
- Usage:
- Emergency lighting
- Certification:
- CE
- Specifications:
- Other
- Warranty(Year):
- 3-YEAR
- Product Name:
- panel lihgt led emergency lighting module
- Input Voltage:
- 85V-265V 50/60HZ
- Charge time:
- 24hrs
- Warranty:
- 3 Years
- Emergency Time:
- 1.5Hrs
- Emergency Power:
- 7W
- Output Voltage:
- 45V
- inverter Size:
- 155*40*30mm
- Outer Casing:
- customized
- Battery:
- Ni-MH
- Supply Ability:
- 20000 Set/Sets per Month
- Packaging Details
- standard export carton
- Port
- Shenzhen or Hongkong
- Picture Example:
![package-img]()
- Lead Time:
Quantity(Sets) 1 - 100 101 - 500 501 - 1000 >1000 Est. Time(days) 10 15 20 To be negotiated
Desription
Sanforce Emergency power packs allow the LED fixtures to meet requirement for emergency illumination.
Designed especially for Constant Current type LEDs and circuits.Supply part of illumination during mains failure to save cost and compy with legal standard at the same time.
Utilizing DC/DC switcher circuitry. Product is compatible with wide range of LED fixture ideal for LED panel light, LED down light,LED ceiling light and many others with external LED driver and low voltage with max 100V.
| Model No. | LMO102C036P |
| Product Name | panel lihgt led emergency lighting module |
| Battery Type | NiMH, NiCd, Lithium battery |
| Lighting Power | 36W LED panel |
| Emergency Power | 7W |
| Input voltage | AC85~265V, 50/60Hz |
| Battery protection | Deep discharge,short circuit,polarity reverse protection |
| Operation temperature | -20--70℃ , 65+20% RH |
| Highest Surface Temperature | 50°C |
| Battery Capacity | 12V 2000mAh Rechargeable Nimh battery pack |
| Charging Time | >24h without break |
| Output Voltage in emergency | DC45V,150mAh |
| Suitable light source | LED PANEL |
| Emergency power | 20% |
| Emergency duration | 90 minutes |
| Product Weight | 1.1kgs |
| Inverter dimension | 155*40*30mm |
| Outer casing size | not equiped but can be customized |
| Note | Custom-Made battery to be configured with different back-up period and different light output levels. |
Features
1)Customized different emergency power level to meet customer"s demand, more economical.
2)Life cycle for emergency inverter can reach 50,000 hour
3)Battery life can reach 500-800 cycles
4)Deep discharge protection,Short-circuit-proof battery connection and polarity reversal protection for battery.
5) 3 years warranty
6)Automatic shutdown of output if LED load is out of range ,Constant power output, Compatible with all dimmable and non-dimmable constant current LED Drive
7)Maximum light output for all LED modules
Sanforce is a manufacturer specializing in emergency conversion kits for LED and fluorescent lighting since 2008.
We cooperate with valuable supply chain, inspect all the incoming materials and set up strict product assurance system, such as SMT, Auto Aging test, Simulation test during our production process. We have very skillful and responsible workers, most of them have been working here over 6 years.
With strong technical support and customer- oriented service, you can be sure that Sanforce is ready to support you, whatever your needs.
1.What is your main product line ?
We are dedicating to LED emergency power pack for commercial lighting, research,
manufacturing and sales, aiming to be a leading emergency lighting backup power producer.
Our main products include:1). Constant current output of Led conversion kit for LED panel
light, LED down lights and other LED light applications with external driver. Emergency
output power differed from 5-90% according to customer’s requirement.
2). 100% emergency output power of emergency kits for LED tube with AC220V or DC110-150V
output.
3). Emergency lighting battery packs for Fluorescent tube 14-98W.
4). High Temperature rechargeable NiCD and NiMH battery pack for emergency control gear
5). Emergency LED T8 tube and min LED T5 3W-4W
6) Constant power emergency kits.
2.Can inverter be commonly used for any type of light applications?
No. It must be confirmed with us case by case
3.What is the difference between high temperature battery and normal temperature battery?
The main difference is that high temperature battery can be trickle charged well even
though the emergency power kit stay at high temperature due to insufficient radiating
caused by the lights working for long time, while normal temperature battery may stop
charging in such conditions that result in emergency light failed to work. We would highly
recommend to use high temperature battery for emergency lighting kit.
