Click on the image to view the original image
- Place of Origin:
- Guangdong, China
- Brand Name:
- Sanforce
- Bulb Type:
- LED
- Battery Type:
- NiMH
- Material:
- plastic
- Usage:
- emergency lighting
- Certification:
- CE
- Specifications:
- LED LIGHTS
- Product Name:
- rechargeable battery for waterproof tube
- Input Voltage:
- 85V-265V 50/60HZ
- Charge time:
- 24hrs
- Warranty:
- 3 Years
- Emergency Time:
- 3H
- Emergency Power:
- 3W
- Output Voltage:
- DC36V
- inverter Size:
- 220*19*11mm
- Battery:
- Ni-MH
- Battery Capacity:
- 7.2V/1500mAh
- Supply Ability:
- 20000 Set/Sets per Month
- Packaging Details
- Inner box size:280*110*57mm
Outer box size:350*295*248mm
- Port
- Shenzhen or Hongkong
- Picture Example:
![package-img]()
- Lead Time:
Quantity(Sets) 1 - 500 501 - 1000 1001 - 2000 >2000 Est. Time(days) 10 15 20 To be negotiated
LED emergency power supply is designed specifically to suit Constant Current type LEDs and ciruits.Utilizing DC/DC switcher circuitry.Product is compatible with wide range of LED fixture ideal for LED panel light light,LED down light and many others with extermal LED driver and low voltage(6~90),emergency output power 5%~100%.
| Model No. | LMO103C003T |
| Product Name | rechargeable battery for waterproof tube |
| Battery Type | NiMH, NiCd |
| Lighting Power | 10W LED tri-proof light |
| Emergency Power | 3W |
| Input voltage | AC85~265V, 50/60Hz |
| Battery protection | Yes |
| Operation temperature | -20--70℃ , 65+20% RH |
| Highest Surface Temperature | 50°C |
| Battery Capacity | 7.2V 1500mAh Rechargeable Nimh battery |
| Charging Time | >24h without break |
| Output Voltage in emergency | DC36V |
| Suitable light source | LED tube, LED tri-proof tube |
| Emergency duration | 180 minutes |
| Product Weight | 600g |
| Inverter dimension | 220*19*11 |
| Note | Custom-Made battery to be configured with different back-up period and different light output levels. |
Description
Emergency conversion kits equipped with slim shape convertor and linear battery pack that is suitable to install into trip-proof LED tube.
Emergency module is invisible and convenient to install on wall, ceiling and any buildings.
Features
- IC controlled Dual rate Charger for energy savings.
- Short circuit protection at battery terminals.
- Battery reverse protection functionality
- Charge indicator and test button. The light fittings guarantee safety of people in buildings open to the general public.
- Automatically actuated in the event of power cuts, these devices (kit + light fitting) offer a good luminous flux to facilitate the evacuation.
- Comply with European standards EN 61 347-2-7 and offer a high level of quality and safety meeting the various prevailing regulations.
- Constant voltage output ,Dial the code to suitable current of luminaires.
Sanforce is a manufacturer specializing in emergency conversion kits for LED and fluorescent lighting since 2008.
We cooperate with valuable supply chain, inspect all the incoming materials and set up strict product assurance system, such as SMT, Auto Aging test, Simulation test during our production process. We have very skillful and responsible workers, most of them have been working here over 6 years.
With strong technical support and customer- oriented service, you can be sure that Sanforce is ready to support you, whatever your needs.
1.Can inverter be commonly used for any type of light applications?
No. It must be confirmed with us case by case
2.What is the difference between high temperature battery and normal temperature battery?
The main difference is that high temperature battery can be trickle charged well even
though the emergency power kit stay at high temperature due to insufficient radiating
caused by the lights working for long time, while normal temperature battery may stop
charging in such conditions that result in emergency light failed to work. We would highly
recommend to use high temperature battery for emergency lighting kit.
3.Does battery have an end-of-charge detection/over voltage protection?
No, The battery is being charged all the time, The charging current will be decreased based
on the capacity status during the charging process. For NiCD and NiMH battery, it is
applicable for constantly charging without any risk even though no over voltage
protection. But under voltage protection is set up for discharging.
4.What are your market reach throughout the region?
Our markets mainly spread over Europe, South of America, Africa and Asian Pacific region as
well as domestic marketing, we have 8 years of experience in foreign trade, we have worked
with buyers of lighting importers and distributors etc.
5.Can the light work as emergency function immediately once we installed the emergency conversion kit into standard lighting applications?
NO
The emergency output is high voltage and high frequency (1000v 230KZ))for fluorescent, That
is not applicable for LED system.
6.Your factory or trading company?
We are a factory, we provide OEM services and accept small order. We only focus on the
manufacturing of products-Emergency Conversion Kits.
7.You have the ability to do independent research and development?
Our engineering department has 3-5 people, we have the research and development
capabilities. We also collect each customer’s feedback regularly, We have the ability on
product improvement and new product development.
