1 | Chip Set | Powerful Ambarella A12 core |
2 | OS | Linux 3.10.73 |
3 | Startup Time | < 3 Seconds (From power on to recording) |
4 | Image Sensor | 1/3 color CMOS sensor |
5 | Image Angle | HOV ≥130° |
6 | Light Compensation | Infrared Light, range up to 10 meters |
7 | IR-Cut | Automatic |
8 | Snap shot | JPG, max resolution up to 7696×4329 (32 million pixels) |
9 | Video Format | H.264 |
10 | Recording Resolution | 1920×1080p30 for recording and 1280×720p30 for 4G live view |
11 | Low Bit Rate | Ambabrella Smart AVC technology for volume saving |
12 | FPS | 30fps/25fps/20fps/15fps/10fps/5fps |
13 | Audio Format | G.711 |
14 | Digital Zoom | 16X |
15 | Dewarp | Dewarp processing for fish eye lens or wide angle lens (coming soon) |
16 | Playback | 1X Playback, 2X Fast Forward/ Reward |
17 | LCD | 320x240, 2.0 inch |
18 | LCD brightness | >500 |
19 | LCD Contrast | ≥2000:1 |
20 | Data Port | Mini USB & 14pin Auxiliary port |
21 | Storage Media | SD Card(SDHC, SDXC up to 256GB) |
22 | GPS | Internal GPS module with time synchronize |
23 | Battery | Replaceable battery, 1950mAh each |
24 | Charging time | ≤3 hours (use the standard power adaptor) |
25 | Pre-record | Pre-record and Post-record time: 1min or adjustable |
26 | Low Power Consumption | <1.0W @1080p30 Recording with audio (without GPS, WIFI, 4G_LTE working) |
27 | 4G standby consumption | 2mA standby current with remote data wake up |
28 | Continuous working time | >12 hours 1080p30 recording (with one backup battery) |
29 | Build-in Modules | Optional GPS, WIFI, 3G/4G_LTE |
30 | Language | Chinese/English/Russian/Thailand (accept all language) |
31 | Charging Base | For battery charging and data transmission |
32 | Dimension | ≤60mm × 85mm ×30mm |
33 | Weight | ≤155g |
34 | Working Temperature | -30℃ ~ 55℃ |
35 | Water Proof | IP66 |
36 | Parameter settings | LCD menu |
37 | Interphone | External analog interphone port |
38 | Wireless | 300Mbps WiFi and 3G/4G_LTE (wifi option) |
