- Place of Origin:
- China
- Brand Name:
- Senken
- Color:
- Black
- Size:
- 85mm*62mm*33mm
- Shell protection level:
- IP65
- Video resolution:
- 2304*1296, 1920*1080, 1280*720, 840*480
- monitor:
- 2.0 inch
- Wide angle:
- 140 degrees
- Supply Ability:
- 5000 Piece/Pieces per Month
- Packaging Details
- 30PCS per carton
- Port
- Ningbo/Shanghai
- Picture Example:
![package-img]()
OS | OS | Linux 3.10.73 |
Booting time | < 12 s | |
Language | English | |
Video | Video input | 1x digital Camera for 1080p/720p/360p recording,available for external camera |
Video output | 2 inch LCD screen | |
Recording Resolution | 1920x1080/1280x720/640x360 | |
Frame rate | ||
Record mode | Record audio and video at the same time | |
Compression | H.264 (High profile up to level 4.1) | |
Audio | Audio input | 1x MIC input, support intercom connection with USB |
Compression | PMC | |
Audio record | Support audio recording | |
Video process | Live video resolution | 1920x1080/1280x720/640x360 |
Photograph | 1920x1080 ~ 8640x4752 | |
Snap | Support snapping during recording(the photo resolution base in recording) resolution) | |
Storage | Built in 16GB TF card(available for 16~128GB) | |
Light source | Flash light | To increase brightness when you are recording or taking a photo |
Laser | Fix the view when you record | |
IR | Up to 10 Meters with Visible shape image at night | |
Two way radio | Talk back | Support two way radio between different devices(only for 4G/3G device) |
Talk back in platform | Support two way radio between device and platform(only for 4G/3G device) | |
Lens | Lens’s angle | >125° |
Alarm | Alarm input | Support alarm input and the alarm can be show in platform |
Interface | USB | 1x USB,for charging, communication with PC, upgrade OS, connect external camera etc |
Network | Protocol | TCP/IP |
3G/4G | Optional,built in 3G/4G module(HSUPA/HSDPA/WCDMA/EVDO/TD-SCDMA/FDD-LTE/TDD-LTE) | |
wifi | Optional,support WIFI connection and AP | |
GPS | GPS | Optional module for BDS/GPS/GLONASS,to record location and speed |
Software | player | Player software, play multiple cameras together, can also play the encrypted file |
CMSV6 | Used for 4G/3G model only, support live view/live tracking/historical track | |
Upgrade | Firmware maintain | Firmware can be upgrade though USB |
Working condition | Temperature | -40--60℃ |
Humidity | 40%~80% | |
Other | Time | synchronize with GPS, internet, PC |
Dual bit stream | Two different bit stream for recording and live streaming via 4G/3G | |
Default | Can set to default setting | |
Indicator | Power,Record,Snap,Audio record | |
Battery capacity | 2600mAh x 2 Replaceable battery, keep NON-4G device running for about 8h,keep 4G device running for about 6h;Charging time is about 4h. | |
Backup battery | 60mA(Optional, keep device running during switch battery) | |
Size | 88.3*59.8*34.4mm | |
Wight | About 165g |
