Features:
- The design of controller separated from the mainframe significantly saves the instaIlation space.
- 7 warning tones Wail1,Wail2,Hi-Lo Yelp,Siren horn,tool,with auto memory function,function of record and radio rebroadcast.
- Both KZQ01 and KZQ02 controllers are selectable to match wlth the mainframe
- Many power from 100Watts 150Watts,200watts,300Watts,to 400Watts are available to meet differant market demand.
- The siren with power of l50watts 200watts 300watts and400Watts has the ability to broadcast two tones at the same time when connecting with two speakers in two channels.
- With light control function to match any version of lightbar supplied from Senken
- Three outputs of Wail 2,lampl and lamp2 could be programmed to be one output.one button controls 3 functions then be realized to enable operation more conveniently
- Hom output could be independently connected to vehicle steer,conveniently for driver to operate the hom tone when needed.
| Model | L×W×H(mm) | Rated Power | Rated Impedance | Sound compression level |
| CJB80J | 149,115,55.5 | 80W | 8Ω | 107-1117dB |
| CJB100R | 149,115,55.5 | 100W | 8Ω/11Ω | 115-120dB |
| CJB150R | 149,115,55.5 | 150W | 6Ω | 117-121dB |
| CJB200R | 149,115,55.5 | 200W | 6Ω | 118-124dB |
| CJB150R1 | 245,115,55.5 | 150W | 8Ω+8Ω | 117-122dB |
| CJB200R1 | 245,115,55.5 | 200W | 8Ω+8Ω | 111-124dB |
| CJB300R1 | 245,115,55.5 | 300W | 6Ω+6Ω | 110-120dB |
| CJB400R1 | 245,115,55.5 | 400W | 6Ω+6Ω | 112-124dB |
