NANHUA LT810A wind tower Solar beacon
Click on the image to view the original image
Product: views:5NANHUA LT810A wind tower Solar beacon
Branch: NANHUA
Unit Price: Negotiated
Min.Order:
Supply:
Delivery: Shipment within days since the date of payment
Valid until: Long Term
Updated on: 2019-10-16 19:53
  Negotiated
Product Details
Overview
Quick Details
Place of Origin:
Shanghai, China
Brand Name:
NANHUA
Model Number:
LT810A
Product name:
solar beacon
International standard:
ICAO(Annex 14) low intensity aviation light and FAA-L810
Application:
airport runway light/taxiway light/wind tower lighting
Solar Cell Type:
Ni-MH
Light source:
LED
Intensity:
>32.5cd
Solar panel:
4W/5V
Autonomy:
7 days
IP protection:
IP 65
Material:
Base:aluminum alloy,Housing:PC
Supply Ability
Supply Ability:
1500 Piece/Pieces per Quarter solar beacon
Packaging & Delivery
Packaging Details
cartons or wooden for solar beacon
Port
shanghai port for LT810A Solar beacon/airport runway light//taxiway/wind tower lighting

Solar beacon



Product Description

NANHUA LT810A Solar beacon/airport runway light//taxiway/wind tower lighting for a wide variety of cranes used in Harbors, Metallurgies, Towers (Telecom, GSM), Smokestacks, Buildings and any other potentially hazardous obstructions to air traffic with a steady burning red safety light





NANHUA LT810A Solar beacon



          •Extremely Reliable — Major Maintenance Cost Saving

          •Corrosion resistance and durability.

          •Use NiMH battery, easy to replace

          • Lamp housing –Polycarbonate, with good anti-impact strength, thermal stability, high transmittance.

          • Combustibility rating: UL94-V0.



NANHUA LT810A Solar beacon/airport runway light//taxiway/wind tower lighting Specifications


International standard

ICAO(Annex 14) low intensity aviation light and FAA-L810

Light source

LED

Vertical degree

≥10°

Light color

red

Horizontal degree

360°

Intensity:

>32.5cd

Flashing rate

20 or 30 or 40times/min(adjustable) Default rate:30times/min

Led life

≥100.000h

On/off lever

70/100Lux

Battery capacity

3.6V/8AH NiMH

Solar panel

4W/5V

Autonomy

7 days(at 25°C, if the temperature is lower than 0°C or above 40°C, it will affect the battery discharge)

Operating temperature

-40°C~+55°C

IP protection

IP65

Relative humidity

10%~95%

Weight

5Kg

Material

Base: Die casting aluminum   Housing: PC





NANHUA LT810A Solar beacon



• Mount the solar light in the most suitable place such as under direct sunlight, to ensure its continuous operation. .

•  Use 3 M8 screws to fasten to the mounting surface, and the surface should leveling and with enough  mechanical strength.

• If operate the light for the first time, open the battery button on the bottom of light base.





NANHUA LT810A Solar beacon


• Replace the battery regularly, it is suggested to replace it once every year.
• If the light be stored for over 6 months, charge the battery at a time.
• Be careful to the bird spike, it is a little sharp-cut.



NANHUA LT810A Solar beacon

  • Unscrew the fixing 6 screws.
  • Disconnect the battery connection, take off the housing.
  • Adjust the red switch on the PCB board, and adjust the flashing rate.

NANHUA LT810A Solar beacon/airport runway light//taxiway/wind tower lighting Battery Replacement

  • Open the battery cover on the bottom.
  • Take off the battery.
  • Replace to the new battery and install the cover.

NANHUA LT810A Solar beacon

  • Model:  NANHUA LT810A Solar beacon/airport runway light//taxiway/wind tower lighting
  • Applications: Applied to iron towers(electicity,telecom, microwave, etc), chimneys(heat-engine plant, coking plant,chemical plant), high buildings, large-scale bridge.large-scale port machinery,large engineer machinery and wind turbines which need the warning for aircraft machines.
  • Standard: ICAO Type B low intensity FAA L-810 CAAC L-810
  • Certificate:
    1. CAAC Certification
    2. Utility model patent certificate/Design patent
  • Improve Records:None
  • Fault Records: None
  • Quantity/Delivery Day: 5pcs/7Days
