Click on the image to view the original image
Application
LED high bay light is applied for the lighting system of various lifting machinery(tyred gantry crane, crawler crane, travelling crane, etc), port machinery (gantry crane, bridge crane, reachstaker, etc), metallurge, chemical industries, mine and marine vessel, etc.
Major functions and feature
• Based on engineering vehicle lighting technology, high power LED light source, it features high luminance, low power consumption and long lifetime.
• Aluminum body features excellent heat emission, anti oxidation ability for long term stable operation.
• Sealed structure, excellent waterproof and vibration resistance capacity
• 180° mounting angle, come with cable, convenient for the cable connection between lamps
Specifications
Operating voltage | AC100V-220V | Lifetime | ≥50,000 hrs |
Power consumption | 48W | Color temperature | 5500K-6000K(Cold White) <2700K (Warm White) |
Operating temperature | -30 ~ +60 | IP rate | IP65 |
Humidity | 10% ~ 95% (no coagulation) | Weight | 1.8kg |
Material | Len: PC Body:aluminum | ||
Installation
•To check the power supply voltage is same as the nominal voltage, connect the lead wire to L,N,
•Fix the lamps to the mounting surface which has enough mechnical strengthen with M10 screws. The mounting angle of the bracket is adjustable within 180°
• Comes with one lead wire to seperately connect the positive and negative of the power supply
• The lamp is lit once powered on.
Note
• Do not reversely connect the power supply
• Do not use it until the bracket and lamps are screwed tightly
• It is normal that the lamp has the temperature rise.
