- Place of Origin:
- Shanghai, China
- Brand Name:
- NANHUA
- Model Number:
- LS130
- Supply Ability:
- 5000 Piece/Pieces per Month
- Packaging Details
- export carton.
- Lead Time:
- Normally 10days,depend on order quantity
Major functions and features:
• LED flashing light ensure extreme long lifetime and low power consumption.
• Aluminum basement supply good ability of heat dissipation.
• Waterproof and Shockproof, corrosion and UV resistance
• Ease of mount
• Two different mounting way for selection, magnet or flange
Specifications:
Voltage | DC12V/DC24V(optional) | Power | 10W |
Alarm | flashing(frequency:7Hz) | Light source | LED |
Color | red,amber(optional) |
|
|
| |||
Working temperature | -20 °C ~ +60°C | IP grade | IP65 |
Working humidity | 10% ~ 95% (non-condensing) | Weight | 0.5kg |
Material | Basement: aluminum, Housing:PC | ||
Mounting & operation:
• Make sure input power same as light rated voltage.
• Mount the device onto mounting surface with 3 M6 screws or magnet, the mounting surface should have enough stength to hold the device
• This light use of low-voltage power supply, wiring the device base on “wiring schematic”
