Home > Products > LP2 explosion proof warning light/ medium intensity
LP2 explosion proof warning light/ medium intensity
Click on the image to view the original image
Product： views：5LP2 explosion proof warning light/ medium intensity
Branch： NANHUA
Unit Price： Negotiated
Min.Order：
Supply：
Delivery： Shipment within days since the date of payment
Valid until： Long Term
Updated on： 2019-10-16 19:53
  Negotiated
Product Details
Overview
Quick Details
Input Voltage(V):
AC 110-240V
CRI (Ra>):
80
IP Rating:
IP66
Working Lifetime(Hour):
100000
Working Temperature(℃):
-30 - +60
Emitting Color:
White
Certification:
CE, EMC, LVD
Place of Origin:
Shanghai, China
Brand Name:
NANHUA
Model Number:
LP102
Light Source:
LED
Products name:
Ex-proof medium intensity aviation obstruction light
Standard:
MH/T 6012-1999, FAA1505345-43G, MH5001-2013
Light source:
LED
Power consumption:
30W
Operating voltage:
AC 110-240V
IP Class:
IP66
Anti-corrosion:
C4/WF1/WF2
Operating temperature:
-30°C~+60°C
Humidity:
10%~95%
Weight:
8Kg
Item Type:
Explosion-proof Lights
Color Temperature(CCT):
Cool White
Supply Ability
Supply Ability:
500 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
standard export package
LP2 explosion proof light
Port
Shanghai

Ex-proof medium intensity aviation obstruction light



Product Description





Application



Ex LED Area light was designed specially to offer the lighting system in a variety of hazardous area applications like oil & gas industry, chemical industry, marine and offshore platform, both indoor and outdoor.,

Applied to gas zon 1 and 2, gas zone IIA, IIB and IIC

Applied to dust zone 21 and 22, temperature class T1-T6.





Major functions and features



•  Aluminum alloy body.

•  PC lens processed by the professional optics design

•  Tempered glass lamp housing with the features of 4J energy impact resistance and thermal shock resistance.

•  Ex d structure design to offer more reliable explosion proof quality.

•  Specialized corrosion resistance, vibration resistance and water & dust proof design, both indoor and outdoor application in the harsh conditions

•  High duty LED light source to ensure long life operation(100,000hrs) and superb energy saving.

•  Constant current design to guarantee the operation stability.



Specifications

Standard

GB3836.1, GB3836.2, GB12476.1, IEC60079-0, IEC60079-1, IEC60079-31

MH/T 6012-1999, FAA1505345-43G, MH5001-2013

Marking

Ex d ⅡC T6 Gb/ Ex tb ⅢC T85℃ Db IP66

Light source

LED

Power consumption

30W

Operating voltage

AC 110-240V (50-60Hz)

Anti-corrosion

C4/WF2

Cable entry

M25*1.5 cable entry, suitable for ø10~ ø14mm² cable

≤2.5mm² conductor

Installation

flange mount (F),bracket mount(A)

luminescent intensity

2000cd±25%

Angle

≥3°(V)/, 360°(H)

Working condition

Flashing (frequency adjustable)

color

red

Operating temperature

-40℃~+60℃

IP Class

IP66

operating humidity

10%~95%

Weight

8Kg







Classification rules





Explosive air condition

Explosive dust condition

Ex-mark

Zone

0

ⅡC



Ex d ⅡC T6 Gb

1,2

1



ⅢC

Ex tb ⅢC T85°C Db

20,21,22
