Solar navigation light
- Applications
- Applying to ocean buoy, river buoy, aquaculture, offshore oil platform, port or other fixing and floating aids to naviation.
Main functions and features
•Based on LED technology, and its color complies to IALA Recommendations E-200-1.
•Integrated design, enabling a rugged and completely waterproof seal capable of prolonged and deep immersion (IP68).
•PC housing,UV resistance, shockproof and corrosion proof. With bird spike.
••256 kinds of flashing rate are available, comply with IALA.
•Intensity is adjustable continuously. Photocell controls On/Off automatically and the value of luminance switch can be adjusted.
•Built in sealed lead acid battery, free maintenance and easy for replace.
•Extremely Reliable and cost saving.
•External charging power is available( Optional) .
•GPS synchronization(Optional).
•GSM faulty alarm function(Optional).
Specifications of solar navigation light
| Optical | |
| Effective intensity | >40cd |
| Visible range | >4 Nautical mile |
| LED color | red,yellow,blue,green,white |
| Vertical degree | >7° |
| Horizontal degree | 360 ° |
| Light source | LED |
| LED lifetime | ≥100,000h |
| Operation | |
| Autonomy | >30 days(14hour darkness,12.5%duty cycle) |
| On/Off level | 300 lux±100lux,end user can adjust it |
| Flashing rate | complies to IALA Recommendations, total 256 available flashing rate( steady burning,adjustable ) |
| Power Supply | |
| Solar panel | monocrystalline silicon solar panel |
| Output | 5W*4 |
| Battery | No maintenance sealed lead acid battery |
| Battery capacity | 12V/12 Ah |
| Physical Characteristics | |
| Integrated housing | UV resistance polycarbonate |
| Waterproof | IP68 |
| Weight | 5.9KG |
| Temperature | -40°C ~ +80°C |
| Size | High 370mm, Diameter 235mm |
| Installation dimension | 235mm 200mm |
| Option | External charging power GPS synchronization GSM faulty alarm function |
NANHUA Electronics Co., Ltd was founded in 1990, has been focused on developing, manufacturing and selling industrial signaling, lighting and controllers more than 27 years.
Based in Shanghai, China, NANHUA has a registered capital of RMB 50 million, with total about 285 employees (including 36 R&D people), and owned the production space of 120,000 square meters. As a high-tech enterprise in Shanghai, NANHUA has gained ISO9001, ISO14001 and OHSAS 18001 certificates.
Aviation obstruction lights as one of the major products of NANHUA, design and manufacturing according ICAO, FAA international and local CAAC standard, and most products have been certified.
NANHUA"s products are widely applied in key projects domestic and abroad. NANHUA is committed to the establishment the benchmark of the top aviation obstruction light equipment.
Our Philosophy
NANHUA believes in a simple philosophy. We focus on providing the best products and service to clients and which is the reason for NANHUA’s existence. We believe that successful enterprise and employee fulfillment can only be realized by long-term hard working.
NANHUA pursues broad perspective and believes that imaginative work can change the world. We expect NANHUA to become an internationally competitive firm. Through constant hard work we anticipate a prosperous future.
NANHUA dedicates herself to creating an equal, free and open working environment. We respect each employee’s uniqueness and hope that all of them will work happily in NANHUA.
Features of Aviation obstacle lights (FAA)
Features of Aviation obstacle lights (ICAO)
Light Type | Colour | Signal type/ (flash rate) | Peak intensity(cd) at given Background Luminance(b) | ||
Day (Above 500cd/m²) | Twilight (50-500cd/m²) | Night (Below 50cd/m²) | |||
Low-intensity,Type A (fixed obstacle) | Red | Fixed | N/A | N/A | 10 |
Low-intensity,Type B (fixed obstacle) | Red | Fixed | N/A | N/A | 32 |
Low-intensity,Type C (mobile obstacle) | Yellow/ Blue | Flashing(60-90fpm) | N/A | 40 | 40 |
Low-intensity, Type D (follow-me, vehicle) | Yellow | Flashing(60-90fpm) | N/A | 200 | 200 |
Low-intensity, Type E | Red | Flashing | N/A | N/A | 32 |
Medium-intensity,Type A | White | Flashing(20-60fpm) | 20 000 | 20 000 | 2000 |
Medium-intensity,Type B | Red | Flashing(20-60fpm) | N/A | N/A | 2000 |
Medium-intensity,Type C | Red | Fixed | N/A | N/A | 2000 |
High-intensity, Type A | White | Flashing(40-60fpm) | 200 000 | 20 000 | 2000 |
High-intensity, Type B | White | Flashing(40-60fpm) | 100 000 | 20 000 | 2000 |
