- Place of Origin:
- Shanghai, China
- Brand Name:
- nanhua
- Model Number:
- FA013A
- Supply Ability:
- 1500 Set/Sets per Month
- Packaging Details
- standard carton.
- Lead Time:
- Normally 10days,depend on order quantity
Features |
l Adopt non-contact magnetic measuring technology, high anti-interference ability and reliablility. l Wide wind measuring range, low starting threshold. l Wind cup and housing adopts maze structure connection design. l Modular design, ease to mount and maintain on site, suit to various industries and application. l Fault tolerant design, product not damage in wrong wiring connection. l Multistage lightning surge design. l Wide voltage design.
|
General Specifications
|
Electrical |
| Mechanical |
|
|
Rated voltage | DC5V~30V | Housing material | PC+ABS+PC |
|
Operating current | Max. 35mA | Wind cup | PC+ABS+PC | |
Lightning surge | IEC61000-4-5 4kV /2kA | Bearing | SS440C |
|
Electrostatic discharge | IEC61000-4-2 air discharge 16kV | Humidity | 0%~100%RH |
|
| IEC61000-4-2 contact discharge 8kV | Operating temperature | Ta-40 °C ~ +70 °C |
|
|
| IP rate | IEC60529 IP65 |
|
|
| Wiring | Aviation plug |
|
|
| Housing color | Black RAL9005 |
|
|
| Weight | 0.2 kg |
|
Meteorological |
|
|
|
|
Starting threshold | ≤0.5m/s Vu=20 °C |
|
|
|
Anti-wind level | >70m/s |
|
|
|
Range | 0~60m/s |
|
|
|
Accuracy | ±0.5m/s(VL<5m/s) |
|
|
|
| ±3% (VL>5m/s) |
|
|
|
Resolution | 0.1m/s |
|
|
|
