Home > Products > LF70XX LED High Mast Light apron high mast lighting
LF70XX LED High Mast Light apron high mast lighting
Click on the image to view the original image
Product： views：2LF70XX LED High Mast Light apron high mast lighting
Branch： NANHUA
Unit Price： Negotiated
Min.Order：
Supply：
Delivery： Shipment within days since the date of payment
Valid until： Long Term
Updated on： 2019-10-16 19:54
  Negotiated
Product Details
Overview
Quick Details
Input Voltage(V):
AC100-240V
Lamp Luminous Flux(lm):
9000
CRI (Ra>):
70
Color Temperature(CCT):
Cool White
Beam Angle(°):
NA
Working Lifetime(Hour):
50000
Lamp Body Material:
Aluminum Alloy
IP Rating:
IP65
Certification:
CE
Place of Origin:
Shanghai, China
Brand Name:
NANHUA
Model Number:
LF70XX
Working Temperature(℃):
-30 - 50
Light Source:
LED
Item Type:
High Mast Lights
LED Light Source:
CREE
Lamp Power(W):
75
Lamp Luminous Efficiency(lm/w):
120
Supply Ability
Supply Ability:
2000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
carton pack or wooden pack according to customer's needs
Port
Shanghai
Lead Time:
in 20 days

Application

Widely used in ports, factories and mines, plazas, overpasses, crossroads and other regions of the high mast and area lighting.



Major Functions and Features

Flat slim shape with high strength design

NANHUA independent design

Use international brand original high-performance light source and power supply, stable and reliable

High-beam professional light distribution design

Modular design, easy for maintenance



Main Specifications



Input Voltage

AC100V~AC240V

Frequency

50Hz~60Hz

Rated Power

560W/440W/300W/220W/150W/75W

CCT

Cool White:5500K-6000K

Warm White:2700K-3000K

LED Lifespan

≥50000hrs

PF

>0.9

Lumens per Watt

Cool White: 120 lm/W

Warm White:100 lm/W

CRI

Cool White:Ra≥70

Beam spread

Special beam for High Mastuse

Warm White:Ra≥80

IP Rate

IP65

IK Rate

IK08

Vibration-resistant Level

1.5G(ANSI C136.31)

Ambient Humidity

10% ~ 95%

(noncondensing)

Material

Housing:Aluminum alloy

Operating Temperature

-30C ~ +50C

Lens:PC

Corrosion-resistant Level

ISO9227  720H





Installation and Operation

•  Lamps need to use M12 screws with anti-off nuts fix to the mounting surface, the mounting surface should be smooth and have sufficient mechanical strength.

• Fix the anti-dropping chain in the proper place, and the fixing surface should have sufficient mechanical strength.

•  Connect the lead wire to the L,N,PE power.

•Lamp external power cord must meet at least 16AWG three-core sheathed cable, sheathed wire diameter 10MM.



Notice

•When lamp in operation, Lamp aluminum lamp body and PC surface has a certain temperature rise, is a normal phenomenon

•  The Minimum distance from the object to be illuminated should be 3 metersto avoid fire.

•The lamp surface shall not be covered when operating.

•  Should cut off the power before lamps’ replacement and maintenanceuntil cooling well, and should be operated by professionals.



Appendix 1:Fixture Lumens



2700K-3000K

5500K-6000K

(lm)

(lm)

560W

56000

67200

440W

44000

52800

300W

30000

36000

220W

22000

26400

150W

15000

18000

75W

7500

9000
