ABC3 warning LED light
This product is used to indicate the conductor power, specially designed for overhead crane, gantry cranes etc.
Main features and functions
• Aluminum enclosure with powdercoat paint finishes, durable and reliable, corrosion resistant, light weight.
• LED light source, long life time.
• Multple seals with silicon rubber, high ingress protection grade.
• Easy to mount, lamp numbers and colors are flexible combination.
Specification
Rated voltage | DV24V/AC110V/AC220V/AC380V/AC460V | Frequency | 50Hz~60Hz |
Rated Power Consumption | <8W (signle light) | Light Color | Red, Yellow, Green, Blue (optional) |
Visible distance | >300m | LEDs life time | 100,000h |
Operating mode | steady burning (flash can be customized) | Wiring | Y type connection |
| |||
Operating Temperature | -30 ~ +70 | IP Rate | IP65 |
Ambient humidity | 10% ~ 95% (non condesation) | Material | Aluminum alloy / Plastic (optinal) |
Mount type | Horizental mount / Vertical mount |
|
|
Installation and operation
• Ensure that the input voltage is correct.
• Fix product to mount face by using four nos. M10 screws (not provided), ensure mount face is flat and has enough mechanical strength.
• Remove 4 nos. screws on enclosure to open the product, refer wiring connection diagram to connect wires to terminal blocks, close the product and fix the screws after wiring.
• Ensure cable connection is correct before power on.
Model selection table
Model | Color (from top to bottom) | Lamp diameter | Cable gland | Weight (KG) |
2-light combination | Red+Green |
Metal
| 4.0 | |
Red+Yellow | 118mm | |||
Green+Yellow | 118mm | |||
3-light combination | Yellow+Green+Red | 118mm | Metal
| 5.7 |
Green+Red+Yellow | 118mm | |||
Red +Yellow+Green | 118mm | |||
Green+Red+Blue | 118mm |
Mounting dimension (unit: mm)
2-light combination ↓
3-light combination ↓
Wiring
Wiring connection
Caution
• Ensure cable connection is correct.
• While product is operating, temperature rise is normal phenomenon.
• While product is operating, do not open proucts, prevent any dangers.
• The product is sealed structure, warranty is terminated if unauthorzied people maintain the product.
• Read these instructions completely and carefully.
