Solar warning light

Application

LT864B Medium intensity solar obstruction light for marking Towers (Telecom, GSM), Smokestacks (heat-engine plant, coking plant, chemical plant etc),Buildings, Port devise, Construction machinery, wind power generator etc for air traffic warning.

Major functions & Features

•  Meets optics standard.

•  Based on LED technology, extremely reliable and cost saving.

•  Shock-proof and corrosion resistant.

•  Built-in connect terninals, and will connect well inside before Ex-work.

•  Combustibility rating:UL94-V0.

•  Highlight LED,LED lifetime more than 100,000hrs.

Specification

Installation and operation

•  When installing the light, pay attention to the solar panel direction, and the solar panel should be towards to the Southern(Northern Hemisphere), the angle between solar panel and horizental level equals to local latitude.

•  Connect solar panel plug to the socket on enclosure, and fix the screws.

•  Open the battery switch, and the light will work normally.

Notice

•  Charge the battery in the following steps if keep this light in store for 3 months:

1,Open the light, and take the battery, then charge the battery using charger;

2,Put the light under the sunlight directly, and open the battery switch, charge the battery by sun energy. Turn off the battery switch after a full charge.

•  Please do not open the control box by yourself when operationg to avoid danger.

•  This product is a sealed structure; should not be tampered with by anyone other than professional installer.

•  Please use this product strictly on accordance with the instruction above.

Product File

• Model:   LT864B solar warning light for Microwave & TV tower
• Applications: Applied to iron towers(electicity,telecom, microwave, etc), chimneys(heat-engine plant, coking plant,chemical plant), high buildings, large-scale bridge.large-scale port machinery,large engineer machinery and wind turbines which need the warning for aircraft machines.
• Standard: ICAO; FAA-L864;MH-T6012-1999
• Improve Records:None
• Fault Records: None
• Quantity/Delivery Day: 5pcs/7Days
