Home > Products > Ra>80 130LM/W SMD LED light source IP65 0-10V Dimmable 200W LED High bay light
Ra>80 130LM/W SMD LED light source IP65 0-10V Dimmable 200W LED High bay light
Click on the image to view the original image
Product： views：2Ra>80 130LM/W SMD LED light source IP65 0-10V Dimmable 200W LED High bay light
Type： UFO LED High Bay Light
Unit Price： Negotiated
Min.Order：
Supply：
Delivery： Shipment within days since the date of payment
Valid until： Long Term
Updated on： 2019-10-16 21:39
  Negotiated
Product Details
Overview
Quick Details
Product Name:
LED High Bay Lights
Power:
200W
Input Voltage:
AC100-277V
LED Chip:
Epistar SMD2835
Luminous:
25320lm
Lighting Efficiency:
130LM/W
Material:
Aluminum+tempered Glass
LED Driver:
Meanwell HBG
Beam Angle:
120 degree
Warranty:
5 years
Type:
UFO LED High Bay Light
Certification:
CE ROHS
Supply Ability
Supply Ability:
20000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
inner box and outer carton box
Inner box dimension: 390*390*210mm (1pcs)
Outer carton dimension:405*405*650(3pcs)
Port
Shenzhen
Product Description

Ra>80 130LM/W SMD LED light source IP65 0-10V Dimmable 200W LED High bay light




Advantages:
  • Completely unique, novel, fashion and slim design, much more beautiful appearance, very popular in the market.
  • No lampshade, easy and convenient to package, transportation and installation, save 60% freight cost and mounting cost.
  • Suspending installation with strong rings, wall mounted and ceiling mounted with thickness bracket, to meet various lighting atmosphere.
  • Adopted structure waterproof design, waterproof grade is IP65, instead of IP54.
  • High lighting efficiency 130LM/W SMD2835, CRI>80, UGR<25.
  • Meanwell HBG Led driver, 5 years warranty.



  Parameters:

Model No.CB2-100-AW-W-01CB2-150-AW-W-01CB2-200-AW-W-01CB2-240-AW-W-01
Power100W150W200W240W
Input VoltageAC100-277V
Frequency50-60Hz
Efficiency130lm/w
IP GradeIP65
Luminous11370-12580lm17030-18820lm22800-25320lm28070-30320lm
DriverMeanwell HBG series (IP67)
LED ChipSMD2835
LED Qty210pcs336pcs420pcs546pcs
MaterialAluminum+Tempered cover
Beam Angle120 degree
Dimmable&Sensor0-10V Dimmable, Wavesensor
Warranty5 years
CertificateCE ROHS are pending





Pictures:





Dimension:



Installation ways:



Applications:

Company Information
About Signcomplex:

1. TUV ISO 9001:2015 certified company.

2. Focus on LED Lighting field for 10 years.

3. More than 600 employees, 50 R&D team, 110 sales team.

4. 3 buildings, over 25,000 square meters factory area.

5. TOP 10 led lighting suppliers in US since 2013.





Signcomplex Product Show room:









Factory scan, sales office:





Lighting Fair:



Signcomplex Equipment, R&D software, Certificates
