5 years warranty 14w 2835SMD led tube T8 led tube led lighting

Click on the image to view the original image

Product：	views：25 years warranty 14w 2835SMD led tube T8 led tube led lighting
Branch：	Signcomplex
Unit Price：	Negotiated
Min.Order：
Supply：
Delivery：	Shipment within days since the date of payment
Valid until：	Long Term
Updated on：	2019-10-16 21:41

Product Details

Overview

Quick Details

Warranty(Years):: 5

Input Voltage(V):: AC100-277V

Lamp Luminous Efficiency(lm/w):: 120

CRI (Ra>):: 80

Working Temperature(℃):: -20 - 40

Working Lifetime(Hour):: 50000

Lamp Body Material:: Aluminum Alloy

IP Rating:: IP44

Place of Origin:: China

Brand Name:: Signcomplex

Model Number:: T8

Light Source:: LED

Product Name:: T8 LED Tube Light

Power:: 14w

Length:: 0.9m

LED type:: SMD2835

Beam angle:: 120 Degree

Power Factor:: 0.90

Material:: Alumimum + PC Cover

Cover:: Clear Cover Frosted Cover

Input voltage:: AC100-277V

CRI:: >80

Item Type:: Tube Lights

Color Temperature(CCT):: Cool White

LED Light Source:: SMD2835

Lamp Luminous Flux(lm):: 1680

Supply Ability

Supply Ability:: 150000 Piece/Pieces per Month

Packaging & Delivery

Packaging Details: Commercial inner box and carton

Port: shenzhen

5years warranty 14w 2835SMD led tube T8 led tube led lighting

S-Tube is an upgraded version CFL tube replacement with LED. It has the best configuration of brightness
and power efficiency.

S-tube is designed to replace medium bi-pin T8 and T12 fluorescent tubes. S-tube fits directly into most
fluorescent fixtures providing a simple upgrade to high quality LED lighting. S-tube is optimized to
provide light outputs comparable to fluorescent and delivers the immediate benefits of white-LED lighting;
long lifetimes, no maintenance, high efficency, no mercury, no recycling, no flickering, no buzzing, instant
start, cold temperature operation, and high quality light. It provides energy savings of up to 75% over
fluorescent applications that require long hours with low occupancy rates such as stairwells, corridors,

warehouses, and remote locations. The high quality S-tube replacement tube is constructed from
extruded aluminum to provide a virtually unbreakable, vandal proof lighting solution.

Why our S-tube?

Much longer life than CFL tube: min. 10 years (suppose that light is on 8 hours per day)
-70%~80% Energy-saving over Fluorescent tubes
-Solid State, high shock/vibration resistant
-Work without ballast, Instant soft-start
-No RF interference, No fickering or buzzing
-Quick and easy installation to minimize retrofit costs
-Minimum maintenance costs, Produce little Heat
-No Mercury and other hazardous materials, fully RoHS-compliant
-Continuous operation for white LEDs (10 years for other colors)
-Rated to operate from -4°F to 104°F [-20°C to 40°C],perfect for
environments with extreme climates
-Epistar+Intermatix LED packaging solution, no patent trouble
-The newest design
-The best cost-effective
-Complete electricity isolation design, safety prove

Features :

Standard length 60cm / 90cm/ 120cm / 150cm
Rated input voltage 100-240V AC, 50/60Hz,maximal input
voltage 277V AC
Power: 9W/ 14w/ 18W / 22W
PF (power factor) >0.92
SMD2835 LED

Technical spec:
