3528 SMD LED Backlight LED Decorative Lighting RGB LED Strip
Click on the image to view the original image
Product: views:23528 SMD LED Backlight LED Decorative Lighting RGB LED Strip
Branch: Signcomplex
Type: Flex LED Strips
Unit Price: Negotiated
Min.Order:
Supply:
Delivery: Shipment within days since the date of payment
Valid until: Long Term
Updated on: 2019-10-16 21:41
  Negotiated
Product Details
Overview
Quick Details
Type:
Flex LED Strips
Input Voltage(V):
12V DC
Lamp Power:
7.2W/M
Lamp Luminous Flux(lm):
230lumen/m
CRI (Ra>):
80
Working Temperature(℃):
-20 - 50
Working Lifetime(Hour):
50000
Lamp Body Material:
PVC
Certification:
CE, RoHS
Place of Origin:
Guangdong, China
Brand Name:
Signcomplex
Model Number:
SC-IB-NW
Application:
LANDSCAPE
Light Source:
LED
Color Temperature(CCT):
/
LED Light Source:
SMD 3528
IP rating:
IP20
Current (Amps/m):
0.6
Stand Length:
5m/roll
LED Q'ty:
30pcs/m
Continuous Connection (m):
10
Beam Angle (degrees):
120
Product Name:
LED Strip
Item Type:
Light Strips
Supply Ability
Supply Ability:
9500000 Meter/Meters per Month we have stock for the smd led light strip
Packaging & Delivery
Packaging Details
package of the ultra bright led strip:
5m a roll. anti-static packing
Port
Shenzhen and Hongkong

3528 SMD LED Backlight LED Decorative Lighting RGB LED Strip







SC-IB


Great advantages:
Eco friendly
Long life span,standard warranty 3 years
Complete cut / connection accessories
No need of constant-current power feed
low power consumption
Custom packing
CCT can be adjusted, wider CCT range
Can display several changing patterns with a controller and remote



Specifications:

Model NumberColorLengthLEDLED TypeLight OutputBeam AngleMax.Power
Consumption
 (W/m)
Current
(Amps/m)
VoltageIP
(m)Q’ty(lumen/m)(degrees)(V DC)
SC-IB-NWNatural White53003528 SMD  3301204.80.41220
SC-IB-WWhite53003901204.80.41220
SC-IB-WWWarm White53003201204.80.41220
SC-IB-RRed5300901204.80.41220
SC-IB-GGreen53002001204.80.41220
SC-IB-BBlue5300801204.80.41220
SC-IB-YYellow5300901204.80.41220
SC-IB-NW2Natural White56006401209.60.81220
SC-IB-W2White56007801209.60.81220
SC-IB-WW2Warm White56006601209.60.81220
SC-IB-R2Red56001701209.60.81220
SC-IB-G2Green56004001209.60.81220
SC-IB-B2Blue56001601209.60.81220
SC-IB-Y2Yellow56001801209.60.81220
SC-IB-RGBRGB51505050SMD2301207.20.61220
SC-IB-RGB2RGB530047012014.41.21220







 We have variety of LED Strip:3528/5050/3014 /3020/5730/2835 led strip,IP20/IP65/IP68/IP67 led strip,Neon Flex,Normal brightness/High brightness/Super brightness/High CRI /Hybrid//Unique led strip,Rigid led strip...





Packing information:





Applications:
Cove lighting
Architectural lights for canopy,corridor,windoe,archway
Backlight or edge lighting for signage
DIY lights for home use
Path and contour marking
Decorative lights for holiday,event,show,exhibition
