SMD2835 IP40 led linear light 1.2m 36w aluminium hanging led line light white

Click on the image to view the original image

Product：	views：5SMD2835 IP40 led linear light 1.2m 36w aluminium hanging led line light white
Branch：	Signcomplex
Unit Price：	Negotiated
Min.Order：
Supply：
Delivery：	Shipment within days since the date of payment
Valid until：	Long Term
Updated on：	2019-10-16 21:42

Product Details

Overview

Quick Details

Warranty(Years):: 3

Input Voltage(V):: AC 100-240V 50/60Hz

Lamp Luminous Efficiency(lm/w):: 100

CRI (Ra>):: 80

Working Temperature(℃):: -20 - 40

Working Lifetime(Hour):: 50000

Lamp Body Material:: fully aluminum extrusion body

IP Rating:: IP33

Certification:: CE, RoHS

Place of Origin:: Guangdong, China

Brand Name:: Signcomplex

Model Number:: led linear light

Application:: HOTEL

Light Source:: LED

Color Temperature(CCT):: Pure White

LED Light Source:: SMD 2835

Lamp Luminous Flux(lm):: 2919

Model number:: SC-SL7250-036-AW-01W

Color:: White

Length:: 1250mm

Beam Angle:: 110°

Reflector:: Milky cover

Weight (Kg):: 1.5

item:: 2835 SMD IP40 1.2m 36w aluminium hanging led line light white

Item Type:: Tube Lights

Supply Ability

Supply Ability:: 980000 Piece/Pieces per Month

Packaging & Delivery

Packaging Details: 1. Net weight:1.5kg
2. Gross weight/Carton: 20.5kg
3. Packing size: 1270X510X155mm
4.1pcs per inner box,10 inner boxes per carton.

Port: Shenzhen and Hongkong

SL7250 Linear Light
SC-SL7250-036-AW-01W
SC-SL7250-036-AW-01NW
SC-SL7250-036-AW-01WW

0.6m 1.2m 1.5m available

Description :
LED linear light is exclusively designed for designer and architect with imagination and personal style. LED linear light adopt premium aluminum profile, different dimension and size,easy to install.
3 types instal lation method: ceiling mounted type, suspended type and embedded type, and different customized dimensions are also acceptable, which can meet instal lation requirement of different fields and occasions.

Features :

1. Color:cool white(5000-6500K), natural white(3700-4500K)
warm white(2700-3200K), other available.
2. Power factor>0.95
3. Beam angle: 110 Degree
4. Saving energy: 50%
5. Life span more than 50,000Hrs
6. IP code: IP40
7. Standard warranty: 3years
8. Fol low CE Certified.

Technical Parameter :

Input Voltage: AC 100-240V 50/60Hz
LED type: 2835 SMD LED
Intput Power: 36W
Reflector: Milky cover

Applications
- Hotels
- Conference/Meeting rooms
- Factories and offices
- Commercial purposes
- Residential / Institution bui ldings
- Schools, col leges, universities and hospitals
-Places which needs energy saving and high color rendering index l ighting.

Specifications :

Model #	CCT	LED Type	Lumen(lm) (±10%)	CRE	Beam angle	Power(W) (±10%)	Voltage (V)	PF	Weight (Kg)
SC-SL7250-036-AW-01W	5000-6500K	2835	2919lm	>80	110°	36W	AC 100-240V 50/60Hz	>0.95	1.5
SC-SL7250-036-AW-01NW	3700-4500K		2977lm	>80	110°	36W
SC-SL7250-036-AW-01WW	2700-3200K		2516lm	>80	110°	36W
