Home > Products > high efficiency 150lm/w 2835 IP65 0.6m 1.2m 1.5m led dust-proof light
high efficiency 150lm/w 2835 IP65 0.6m 1.2m 1.5m led dust-proof light
Click on the image to view the original image
Product： views：2high efficiency 150lm/w 2835 IP65 0.6m 1.2m 1.5m led dust-proof light
Branch： Signcomplex
Unit Price： Negotiated
Min.Order：
Supply：
Delivery： Shipment within days since the date of payment
Valid until： Long Term
Updated on： 2019-10-16 21:42
  Negotiated
Product Details
Overview
Quick Details
Warranty(Years):
5
Input Voltage(V):
AC100-277V 50/60Hz
Lamp Power(W):
30
Lamp Luminous Efficiency(lm/w):
150
CRI (Ra>):
80
Working Temperature(℃):
-20 - +45
Working Lifetime(Hour):
30000
Lamp Body Material:
Aluminum Alloy
IP Rating:
IP65
Certification:
CE, RoHS, SAA, UL
Place of Origin:
Guangdong, China
Brand Name:
Signcomplex
Model Number:
led tri-proof light
Light Source:
LED
Model No.:
TP-030-AW-WW-H-03
CCT:
2700-3200K
Lamp cover:
Frost/Clear
Beam(angle°):
230°
PF:
>0.9
Saving energy:
80% compared CFL
Max.Current(Amps):
0.4
Product Name:
led dust-proof light
item:
high efficienty 150lm/w 2835 IP65 0.6m 1.2m 1.5m led dust-proof light
Item Type:
Tube Lights
Color Temperature(CCT):
Warm White
LED Light Source:
SMD 2835
Lamp Luminous Flux(lm):
3800
Supply Ability
Supply Ability:
950000 Piece/Pieces per Month We have stock for the led dust-proof light
Packaging & Delivery
Packaging Details
the 20w led tri proof light
Single package dimension:690*80*80mm
Outercarton dimension: ,12pcs/caron(gross weight14kg) 700*340*270mm
Port
Shenzhen and Hongkong
Lead Time:
Shipped in 15 days after payment

high efficiency 150lm/w 2835 IP65 0.6m 1.2m 1.5m led dust-proof light





Tri-proof LED Lamp

TP-030-AW-W-H-03





Description:
This product use durable long life span LED as light source, smooth light without glare, simple looking design.Impact-proof, water-proof and dust-proof, IP rating is up to IP65, can be used in different environment. Use aluminum alloy and PC as the material which ensure that it can work stably in different environment.




Features:
1. ArcS I series tri-proof lamp with 230°beam angle to replace fluorescent tube;
2.Water-proof,dust-proof,impact-proof design,can be used in harsh environment;
3.Use fire-resistant PC cover, can pass 650°glow wire test;
4.High efficiency, up to 140 lm/w;
5.External power supply, easy to maintain;
6.Anti-glare cover, protect eyes better.



Technical parameters:

Model NumberColorLED Type
/Quantity		Light output
(lumen)		Beam angle
(degrees)		CCTCRIMax.Current
(Amps)		Power
(W)		VoltagePF
TP-030-AW-W-H-03whiteSMD2835
LED
(216pcs)		40702305500-6500K>800.430AC100-277V
50/60Hz		0.9
TP-030-AW-NW-H-03natural white39302304000-4500K
TP-030-AW-WW-H-03warm white38002302700-3200K





Main Applications :
Suitable for workshop, warehouse, parking lot, shopping mal l, farm, gas station, etc.



Production line:
