Signcomplex ip65/ip20 RGB/W smd3020 5mm wide led flexible strip

Click on the image to view the original image

Product：	views：2Signcomplex ip65/ip20 RGB/W smd3020 5mm wide led flexible strip
Branch：	Signcomplex
Type：	Flex LED Strips
Unit Price：	Negotiated
Min.Order：
Supply：
Delivery：	Shipment within days since the date of payment
Valid until：	Long Term
Updated on：	2019-10-16 21:42

Product Details

Overview

Quick Details

Type:: Flex LED Strips

Input Voltage(V):: 12V/24V

Lamp Power:: 96W

Lamp Luminous Flux(lm):: 1217

CRI (Ra>):: 80

Working Temperature(℃):: 20 - 40

Working Lifetime(Hour):: 30000

Lamp Body Material:: PVC

Certification:: CE, EMC, LVD, RoHS

Place of Origin:: Guangdong, China

Brand Name:: Signcomplex

Model Number:: SC-BID

Light Source:: LED

Product Name:: 5mm wide led flexible strip

Packing:: 5M/reel + accessories

PCB width:: 10mm

Beam Angle:: 120Degree

IP Rating:: IP20 IP65 IP68

LED Quantity:: 600PCS

Power:: 19.2W/M

length:: customised length is available

Color bin:: We can keep your color bin to confirm the color is the same

Item:: Signcomplex ip65/ip20 RGB/W smd3020 5mm wide led flexible strip

Item Type:: Light Strips

Color Temperature(CCT):: CW

LED Light Source:: SMD3020

Emitting Color:: W/NW/WW

Supply Ability

Supply Ability:: 80000000 Meter/Meters per Month we have stock for 5mm wide led flexible strip

Packaging & Delivery

Packaging Details: 5 meters/reel as an unit wrapped around a disk, each disk is packed by anti-static bag.

Port: Shenzhen and Hongkong

Lead Time:: 5-12 working days after we confirm payment

Flexmond3020 high brightness ,It is the brightest flexible LED strip available in the market

Application

-Cove lighting
-Architectural lights for canopy,corridor,window,archway
-Backlight or edge lighting for signage
-DIY lights for home use
-Path and contour marking
-Decorative lights for holiday,event,show,exhibition

Printed circuit board layout

Technical parameters

Signcomplex is an expert led striplight manufacturer for 7 years,we are dedicated in offering high level led striplight.

Thanks to the consistent high quality,3 years warranty and good after sale service.

Signcomplex has become one of the leading enterprise in led striplight field.

Available models:

3528 60leds/m ,120leds/m,240leds/m.

5050 30leds/m. 60leds/m.

Super bright 3020 120leds/m.

Super bright 3014 60leds/m,120leds/m,204leds/m.

WW+W CCT dimmable models.

RGB+W changeable models.

Digital striplight models.

Model Number	Color	Light Outpu (lumen/m)	LED Q’ty	LED Type	Length (m)	Beam Angle (degrees)	Voltage (V DC)	Current (Amps/m)	Max.Power Consumption (W/m)	IP	Continuous Connection (m)
SC-BID-W	White	1217	600	3020 SMD LED	5	120°	12	1.6	19.2	20	5
SC-BID-WW	Warm White	850
SC-BID-NW	Natural White	1085
SC-BID-W-24V	White	1217					24	0.8
SC-BID-WW-24V	Warm White	850
SC-BID-NW-24V	Natural White	1085
