shenzhen Signcomplex IP20 SMD3528/5050 cheap led strip

Click on the image to view the original image

Product：	views：2shenzhen Signcomplex IP20 SMD3528/5050 cheap led strip
Branch：	Signcomplex
Type：	Flex LED Strips
Unit Price：	Negotiated
Min.Order：
Supply：
Delivery：	Shipment within days since the date of payment
Valid until：	Long Term
Updated on：	2019-10-16 21:42

Product Details

Overview

Quick Details

Type:: Flex LED Strips

Input Voltage(V):: 12VDC

Lamp Power:: 4.8w/m

Lamp Luminous Flux(lm):: 320lm/m

CRI (Ra>):: 80

Working Temperature(℃):: -20 - +40

Working Lifetime(Hour):: 50000

Lamp Body Material:: PC

Certification:: CE, EMC, RoHS

Place of Origin:: Guangdong, China

Brand Name:: Signcomplex

Model Number:: SC-IB-WW

Light Source:: LED

Beam Angle(°):: 120

LED Quantity:: 300

Color:: White/Warm White/Natural White

Current (Amps/m):: 0.4

IP Rating:: IP20

Length (m):: 5

Product Name:: cheap led strip

item:: shenzhen Signcomplex IP20 SMD3528/5050 cheap led strip

Item Type:: Light Strips

Color Temperature(CCT):: Warm White

LED Light Source:: 3528 SMD LED

Emitting Color:: Natural White

Supply Ability

Supply Ability:: 65000000 Roll/Rolls per Month we have stock for the cheap led strip

Packaging & Delivery

Packaging Details: 5 meters/reel as an unit wrapped around a disk, each disk is packed by anti-static bag.

Port: Shenzhen and Hongkong

Lead Time:: 5-10 working days after we confirm payment

SC-IB

Application
Cove lighting
Architectural lights for canopy,corridor,windoe,archway
Backlight or edge lighting for signage
DIY lights for home use
Path and contour marking
Decorative lights for holiday,event,show,exhibition

Great advantages of the cheap led strip
Eco friendly
Long life span,standard warranty 1 years
Complete cut / connection accessories
No need of constant-current power feed
Low power consumption
Custom packing

Technical parameters of the cheap led strip

Model Number	Color	Length	LED	LED Type	Light Output	Beam Angle	Max.Power Consumption (W/m)	Current (Amps/m)
Model Number	Color	(m)	Q’ty	LED Type	(lumen/m)	(degrees)	Max.Power Consumption (W/m)	Current (Amps/m)
SC-IB-NW	Natural White	5	300	3528 SMD	330	120	4.8	0.4
SC-IB-W	White	5	300	3528 SMD	390	120	4.8	0.4
SC-IB-WW	Warm White	5	300	3528 SMD	320	120	4.8	0.4
SC-IB-NW2	Natural White	5	600	3528 SMD	640	120	9.6	0.8
SC-IB-W2	White	5	600	3528 SMD	780	120	9.6	0.8
SC-IB-WW2	Warm White	5	600	3528 SMD	660	120	9.6	0.8

Model Number	Color	Light Outpu (lumen/m)	LED Q’ty	LED Type	Length (m)	Beam Angle (degrees)	Voltage (V DC)	Current (Amps/m)	Max.Power Consumption (W/m)	IP	Continuous Connection (m)
SC-BID-W	White	1220	600	3020 SMD LED	5	120°	12	1.6	19.2	20	5
SC-BID-WW	Warm White	850
SC-BID-NW	Natural White	1090
SC-BID-W-24V	White	1220					24	0.8
SC-BID-WW-24V	Warm White	850
SC-BID-NW-24V	Natural White	1090
