Home > Products > 5 Years Warranty SMD 2835 130lm/Watt 4ft 18W T8 LED Tube Light
5 Years Warranty SMD 2835 130lm/Watt 4ft 18W T8 LED Tube Light
Click on the image to view the original image
Product： views：35 Years Warranty SMD 2835 130lm/Watt 4ft 18W T8 LED Tube Light
Branch： Signcomplex LED Tube Light
Unit Price： Negotiated
Min.Order：
Supply：
Delivery： Shipment within days since the date of payment
Valid until： Long Term
Updated on： 2019-10-16 21:44
  Negotiated
Product Details
Overview
Quick Details
Warranty(Years):
5
Input Voltage(V):
100~240
Lamp Luminous Efficiency(lm/w):
130
CRI (Ra>):
80
Working Temperature(℃):
-20 - 40
Working Lifetime(Hour):
50000
Lamp Body Material:
Aluminum
IP Rating:
IP44
Certification:
CE, RoHS
Place of Origin:
Guangdong, China
Brand Name:
Signcomplex LED Tube Light
Model Number:
ST8
Light Source:
LED
Lamp Luminous Flux(lm):
2680
LED Light Source:
SMD2835
Power:
18W
Voltage:
AC100~277V
LED chip:
2835
Driver:
Isolated,safe
Luminous flux:
2680LM
CRI:
>80
Warranty:
5 Years
Cover:
clear/frosted
Item Type:
Tube Lights
Supply Ability
Supply Ability:
50000 Piece/Pieces per Month LED Tube Light UL
Packaging & Delivery
Packaging Details
LED Tube LightPACKING
Common industrial packaging,Inner box and carton
4ft T8 LED Tube
Port
SHENZHEN

5 Years Warranty SMD 2835 130lm/Watt 4ft 18W T8  LED Tube Light



The main advantages for t8 LED Tube Light
Single Isolated driver,safty.
Heat sink with Pure Aluminum 6063, excellent heat disspation
100% in house 1000V high voltage test .
Alternative color temperature range 2700K~6500K
CRI ≥ 80.(soft and comfortable light.no dazzling)
High luminous effiency:130lm/W
PF>0.95
5 years warranty.

The specification for LED Tube Light
Watt:18W
length:1200mm
Voltage:AC 100-277V
LED Type:SMD 2835
Luminous flux: 2680 lm
CRI>80
PF>0.95
Color:Pure white/warm white/cool white
Cover:Clear/Frosted
Certification CE ROHS FCC TUV certified



Dimensions   (Unit: mm/inch)

Installation  Drawing







Trade Show Pictures

Company Showroom

Warehouse & Production line

Company Image
