35w SMD 2835 led panel 600 600
6060-F Series High Brightness Version
SC-PSC24CE6060-S35W
SC-PSC24NE6060-S35W
SC-PSC24WE6060-S35W
Description of the led panel 600 600
LED Square Panel Light . Using Light Guide Plate, it has the feature of uniform and smooth l ight beam,low glare rating, low l ight pol lution, and excel lent protection from eyestrain. It can be widely used as interior lighting in shops, supermarkets, mal ls and hospitals, etc
Features of the led panel 600 600
1. Color:cool white(5000-6500K), nature white(3700-4500K)
warm white(2700-3200K), other avai lable.
2. Power factor>0.95
3. UGR<19
4. Beam angle: 110 Degree
5. Saving energy: 50%
6. Life span more than 36,000Hrs
7. IP code: Ip40
8. Standard warranty: 3years
9. Follow RoHS and CE Certified.
Technical Parameter of the led panel 600 600
Input Voltage: AC100-240V 50-60Hz
Max Current: 0.85A
LED type: 2835 SMD LED
Output Power: 35W
Reflector: Opal color PC
Specifications of the led panel 600 600
| Model | Color | LED Type | CCT | Power | CRI | Light Output | Voltage | Beam angle | Weight |
SC-PSC24CE6060-S35W
| Cool White
| SMD 2835 | 5000-6500K | 35W | >80 | 2858lm | AC100-240V | 110° | 3.4kg |
nature white
| SMD 2835 | 3700-4500K | 35W | >80 | 2866lm | AC100-240V | 110° | 3.4kg | |
| Warm White | SMD 2835 | 2700-3200K | 35W | >80 | 2824lm | AC100-240V | 110° | 3.4kg |
Applications
- Hotels
- Conference/Meeting rooms
- Factories and offices
- Commercial purposes
- Residential / Institution buildings
- Schools, col leges, universities and hospitals
-Places which needs energy saving and high color rendering index lighting.
Aging test:
