Home > Products > 4 wire conventional smoke detector with relay output
4 wire conventional smoke detector with relay output
Click on the image to view the original image
Product： views：44 wire conventional smoke detector with relay output
Branch： SUMRING
Size： 10.6X10.6X5.2 cm
Unit Price： Negotiated
Min.Order：
Supply：
Delivery： Shipment within days since the date of payment
Valid until： Long Term
Updated on： 2019-10-16 21:24
  Negotiated
Product Details
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
SUMRING
Model Number:
SR-802PC-4
color:
white
Operating voltage:
DC9~35V
Static current:
12mA(NC);500uA(NO)
Alarm current:
10mA(NC);18mA(NO)
Sensitivity:
0.5dB/m(±0.01dB/M)
Alarm output:
Relay output
Installation:
Ceiling mounted
Dimension:
104*49mm

Packaging & Delivery

Selling Units:
Single item
Single package size:
10.6X10.6X5.2 cm
Single gross weight:
0.25 kg
Package Type:
white box or neutral color box
Lead Time:
Quantity(Piece)1 - 500>500
Est. Time(days)10To be negotiated

4 wire conventional smoke detector with relay output









Product Description
Main Features:

 1.SR-802PC-4 is 4-Wire Network Photoelectric smoke alarm

2.Power supply non-polar input

3.Infrared photoelectric sensor

4.MCU processing, eliminate false alarm

5.SMT manufacture technology, high stability

6.Dustproof, mothproof, anti-light interference design

7.Stainless steel shield, anti-RFI(20V/m-1GHz)

8.Execute criterion:UL268, GB4715, EN54-7





Technical specification:

Operating voltageDC9~35V
Static current12mA(NC);500uA(NO)
Alarm current10mA(NC);18mA(NO)
Sensitivity0.5dB/m(±0.01dB/M)
Alarm outputRelay output
InstallationCeiling mounted
Working environment-10℃~+50℃(≤95%RH No congelation)
Dimension 104*49mm







Product Pictures:









Company Information



FAQ



Packaging & Shipping

Packaging information



Shipping information

* Express(UPS, DHL, Fedex, EMS, etc) is available.

* Sea and Air delivery is available

* welcome your agent to deal with our products .
