New product ideas 2019 Network smoke detector 12v for fire safety system
New product 2019 Network smoke detector 24V for fire safety system
SR-812PC-2 is 2-Wire Network Photoelectric smoke alarm
Main features:
1.Power supply non-polar input
2.Infrared photoelectric sensor
3.MCU processing, eliminate false alarm
4.REMOTE LED indicating alarm
5.SMT manufacturer technology, high stability
6.Dustproof, mothproof, anti-light interference design
7.Stainless steel shield in chamber, anti-RFI(20V/m-1GHz)
8.Execute criterion: GB4715,EN54-7, UL539
Technological details
| Model No. | SR-812PC-2 |
| Operating voltage | DC9~35V |
| Alarm temperature | N/A |
| Static current | 20uA |
| Alarm current | 35mA@DC12V;83m@DC24V |
| Alarm output | Remote LED indicator |
| Installation | Ceiling mounted |
| Sensitivity | 2.06%ft±1.3%ft |
| Working environment | -10℃~+50℃(≤95%RH No congelation) |
| Dimension | 100*46mm |
Product pictures:
1:Can I get one sample for test before big order ?
Sure, you can.Please leave a message we will contact you soon.
2. Can I customized LOGO?
Yes you can. Packaging, products, instructions can be printed logo.
3. Can I customized functions?
Yes you can, we have professional R&D team to support best service, and give you best suggestions.
4. How about the quality of your products?
Our raw materials are purchased from qualified suppliers. And we have a strong quality control team to guarantee our products quality.
5. How long is your products quality warranty?
The warranty period is 2 years from the factory, if there are individual quality problems, we will replenish the customer in the next batch of orders
6. When can you ship out my order after my payment?
Normally samples order: about 5-7 days; mass order 2-3 weeks.
7. Can I visit your factory and company office?
Sure, welcome ,any time!
Packaging information
Shipping information
* Express(UPS, DHL, Fedex, EMS, etc) is available.
* Sea and Air delivery is available
* welcome your agent to deal with our products .
