- Place of Origin:
- Guangdong, China
- Brand Name:
- SUMRING/OEM
- Model Number:
- SR-813PC-2
- Product name:
- conventional photoelectric fire detector hard wiring smoke detectors
- Usage:
- Fire Protection
- Color:
- White
- Operating voltage:
- DC10-30V
- Alarm temperature:
- N/A
- Static current:
- 20μA
- Alarm current:
- 35mA@DC12V;83m@DC24V
- Alarm output:
- Remote LED indicator
- Installation:
- Ceiling amounted
- Dimension:
- 100*48mm
- Supply Ability:
- 50000 Piece/Pieces per Month smoke detector
- Packaging Details
- carton or neutral color box
- Port
- FOB shenzhen
- Picture Example:
![package-img]()
- Lead Time:
Quantity(Pieces) 1 - 500 >500 Est. Time(days) 15 To be negotiated
lpcb conventional photoelectric fire detector hard wiring smoke detectors
Features of Conventional smoke detector for fire alarm system :
1.Photoelectric - ideal for detecting smouldering fire
2.2-wire, 4-wire connection click here to 4 wire
3.Wide operating voltage range; Power Supply Non-Polar
4.MCU Processing; High resistance to false alarms
5.Compatible with general fire alarm control panels
6.Ceiling/wall mountable
7.Red LED indicates that the detector is operating properly and alarm mode
8.Power-Off Reset; Remote LED Indicator (2 Wire) click here to 4 wire
9.Alarm Relay N.C. or N.O. Optional (4 Wire) click here to 4 wire
10Stainless Steel Shield in Chamber; Anti-RFI
11.Power supply non-polar input;
12.Execute criterion: GB4715, EN54-7, UL539;
Model No. | SR-813PC-2 |
Operating voltage | DC10-30V |
Alarm temperature | N/A |
Static current | 20μA |
Alarm current | 35mA@DC12V;83m@DC24V |
Alarm output | Remote LED indicator |
Installation | Ceiling amounted |
Sensitivity | 0.15dB/m (±0.03dB/m) |
Working environment | -10°C~+50°C (≤95%RH No congelation) |
Dimension | φ100*48mm |
| Delivery Time | |
| Sample order | 1-3 working days |
| Bulk order | 25-35 working days |
| Stock order | 7-10 working days |
