Click on the image to view the original image
- Applicable Industries:
- lab/hospital/facotry
- Place of Origin:
- China
- Brand Name:
- Hanbang
- Warranty:
- 1 Year
- After-sales Service Provided:
- Video technical support, Overseas service center available
- Display:
- LCD display, with three levels:high,middle,low
- Illumination:
- ≥300LX
- Material 1:
- Main Body: Cold-rolled steel with anti-bacteria powder coating
- Material 2:
- Work Table:304 stainless steel
- Pre-filter:
- Polyester fiber, washable
- Hepa filter:
- 99.999% efficiency at 0.3um
- Cleaning Type:
- Industrial Ultrasonic Cleaner
- Certification:
- CE, ISO9001-2008
- Dimension(L*W*H):
- 990 *750 *1620mm
- Supply Ability:
- 500 Set/Sets per Month
- Packaging Details
- wooden pallet orpackage can be available according to customer's requirements
- Port
- Shanghai
- Picture Example:
![package-img]()
![package-img]()
- Lead Time:
Quantity(Pieces) 1 - 10 >10 Est. Time(days) 10 To be negotiated
Main Application
Clean bench is the use of efficient air purification unit, a higher level of manufacturing clean area for low level clean room, local work environment cleanliness requirements of the higher places, it can save a lot of initial investment and operating costs.
With professional technology design, and manufacture of new vertical unidirectional flow clean bench, this device is widely used in photoelectric prompt, microelectronics, aseptic packaging, food, medical equipment, pharmaceuticals, clean paint and other industries.
Configration | Horizontal flow clean bench | Vertical flow clean bench | |||||
Model | HB-CJ-A1 | HB-CJ-A2 | HB-CJ-B1 | HB-CJ-B2 | |||
Outline dimension(mm) | 900 X 700 X 1430 | 1500 X 700 X 1430 | 990 X 750 X 1620 | 1500 X 750 X 1620 | |||
Power(kw) | 0.4 | 0.8 | 0.4 | 0.8 | |||
Size and Qty of Light | 20w X 1 | 40w X 1 | 20w X 1 | 20w X 2 | |||
Size and Qty of UV Light | 36w X 1 | 36w X 2 | 36w X 1 | 36w X 2 | |||
Noise(dB) | ≦62 | ||||||
Average air Volume(m3/h) | 0.30-0.60m/s (Adjustabie) | ||||||
Cleanliness class | 100@≥0.5μm FED209E | ||||||
Product characteristics
1.Horizontal manifold, open type bench and convenient operation. The clean bench is equipped with a differential pressure gauge, and thus the change situation of the resistance of the efficient filter can be mastered at any time;
2.The fan system with adjustable air volume is adopted, and the light touch type switch is used for adjusting the voltage;
3.Ensure that the wind speed in working area is always in the ideal state;
4.The working bench is made of imported stainless steel;
Q1:May I have samples?
A1:Yes.Sample cost can be refunded if you place formal orders in the future. You just need to advise consignee's contact information and courier account Number. If you don't have a courier account,we will calculate freight cost for you and prepay it.
Q2:What's your MOQ?
A2: Usually we don't have MOQ issue for standard HAN STAT brand units.If you need OEM or ODM service,we'll have a MOQ of 300PCS for device and MOQ of 800PCS for the package.But we're very flexible.Any trial order whose quantity is lower than our MOQ is also welcome.
Q3. Is there any discount price can be offered?
A3: Depending on the number of your bulk, as well as for the prepaid orders, Discount will be considered accordingly.
Q4: When's your delivery time?
A4: Generally, 3-7 working days for existing samples, within 30 days for mass production.
Q5:How can I pay?
A5:We recommend Trade Assurance service on the Alibaba platform.T/T,L/C,Western Union,MoneyGram ect are all acceptable.
