Click on the image to view the original image
1. Unique and elegant appearance
2. Concealed hook,easy to carry
3. NdFeB magnet
4. End cap color: Green/ Bulb /White
5. Three-way switch, anti wrong touching design
Specification
Specification | ||
Model NO. | QF-169B2 | |
Rated Power | 5W | |
Product Size | 32*32*220mm | |
LED Chip | 51 pcs Epistar SMD 2835 | |
Battery | 2600mAh Lithium Battery | |
CCT | 8000K | |
Lumen | 400 lm(full light) | |
Solar Panel | 6V, 1.8WPolycrystalline silicon solar panel | |
Model No. | QF-169A2 | QF-169B2 | QF-169A3 | QF-169B3 |
LED Lamp Size | 32*32*220mm | 32*32*220mm | 32*32*320mm | 32*32*320mm |
LED Chip Qty. | 51pcs SMD 2835 | 51pcs SMD 2835 | 75pcs SMD 2835 | 75pcs SMD 2835 |
Battery Capacity | 2600mAh | 2600mAh | 4000mAh | 4000mAh |
Rated Power | 5W | 5W | 8W | 8W |
Lumen | 400 lumen | 400 lumen | 640 lumen | 640 lumen |
Solar Panel or Not | No | Yes | No | Yes |
Charging Time | 9Hrs | 9Hrs | 14Hrs | 14Hrs |
Working Time | 6Hrs | Input Voltage | DC 5V |
End Cap Color | Blue/ White/Green | CCT | 8000K |
Switch | Three-way switch button | CRI | 80Ra |
Beam Angle | 120 degree | Ambient Temp. | -40-45℃ |
Battery Lifetime | Charging over 1000 times | Solar Panel Cable Length | 3 meters |
Solar Panel | Polycrystalline silicon | Solar Panel Size | 140*130*17mm |
Solar Panel Power(Max) | 1.8W | Solar Panel Current(Max) | 0.3A |
Solar Panel Voltage(Max) | 6V |
Product Description
Design Features:
PC cover
High quality imported PC Cover, 80% Light Transmission，creates even and gentle light effect, no glare
no dark spots and uniform luminanceHousing Material
6063 Aluminum,commonly used for aluminium
extrusion. It allows complex shapes to be formed
with very smooth surfaces fit for anodizing and so
is popular for visible architectural applications
LED Chip
Epistar SMD 2835
80Ra, 8000K, over 50000 hours life time.
5W with 51pcs SMD and 7W with 75pcs SMD.
no glare,no dark spots and uniform luminance
Battery
1. Built-in 3.7V Lithium battery
2. 5W with 2600mAh and 8W with 4000mAh capacity
3. Battery Lifetime: can be charged for over 1000 times
4. MSDS passed
Driver
Smart driver inside, overvoltage & overcurrent IC protection to ensure safety.
Installation Process
Applications
Certifications
Company Information
There are many hundreds of LED bulbs on the market, so why would you chose SZWQF?
Inflated claims about lifespan and colour quality of cheap LED’s have led to some people being disappointed in the product and unwilling to invest further in the technology. But not all LED’s are born equal. SZWQF has spent 7 years sourcing the very best components and design to bring you a quality product you can rely on, at a reasonable price.
FAQ
Q1. Can I have a sample order for led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A:Sample needs 1-2 days, mass production time needs 1-2 weeks for order quantity more than 500pcs
Q3. Do you have any MOQ limit for led light order?
A: Our MOQ is 50 pcs. Sample orders acceptable
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for led light?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6. Is it OK to print my logo on led light product?
A: Yes.We have a laser machine. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 1 years warranty to this multi functional portable led lamp.
Q8: How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less
than 0.2%.
Secondly, during the guarantee period, we will send new lights with new order for small quantity. For
defective batch products, we will repair them and resend them to you or we can discuss the solution i
ncluding re-call according to real situation.
