Overview
Quick Details
- Place of Origin:
- Guangdong, China
- Brand Name:
- VEISE
- Bulb Type:
- LED
- Material:
- Cold Rolled Steel Sheet, Die-casting Aluminum Alloy Base + PC lampshade + aluminum base(ADC12)
- Usage:
- safety
- Certification:
- CE
- Specifications:
- 24 X 1w
- LED Chip:
- 24x1W High Intensity LED
- Color Temperature(CCT):
- 1800k amber
- Luminous intensity:
- >250 cd(0°~Night)
- Flash frequency:
- 2 Hz ≤F ≤ 4 Hz
- Free Operating Voltage:
- DC10-32V(DC48V Custom-made)
- Brand:
- VEISE
- Shockproof Rate:
- 10G
- Waterproof Rate:
- IP69K
- Waranty:
- 3 Years
Supply Ability
- Supply Ability:
- 20000 Piece/Pieces per Month
Packaging & Delivery
- Packaging Details
- Standard Neutral Packing
- Port
- Guangzhou / Shenzhen
- Picture Example:
![package-img]()
28W IP69K Waterproof LED Strobe Warning Lights for Engineering Trunk
Replacing old incandescent lighting with the latest LED technology provides an optimum warming signal image with low power consumption. The combination of thermal management and optics in one module makes an incredible compact design possible. polycarbonate lense is highly impact resistant and extremely durable.
| IP69K Waterproof LED Warning Lamp (MODEL:DF-J-FY24F) |
| LED:24x1W High Intensity LED’s |
| Maximum Power Consumption: 28Watts |
| Luminous intensity:>250 cd(0°~Night) |
| Waterproof Rating:100% IP69K(100KPa) |
| Color Temperature: 1800K (Amber) |
| Flash frequency:2 Hz ≤F ≤ 4 Hz |
| Approval:ECE R65/ R10(EMC) /SAE J845 Class 1 |
| Light Color: Amber/ Red/ Blue (option) |
| Alarm way:6+Flashing & Rotating Patterns via Internal Momentary Switch |
| Visibility: 360 Degree |
| Material:Die-casting Aluminum Alloy Base + PC Lampshade + Aluminum Alloy Heat Dissipation Column |
| Optics Inner Lens:Hybrid Wide-Angle Reflector *3 |
| Mounting: Flexible DIN Pole Mount |
| Operating temperature: -40℃ to +65℃ |
| Warranty: 3 years |
| Shockproof: 10G |
| Free Operating Voltage::DC10-32V(DC48V Custom-made) |
| Weight::600g |
| Dimensions:193(H) x93(D) mm |
| Widely used in construction vehicles (excavators, logging machines, rollers bulldozers, cranes, mining vehicles, agricultural machinery, ambulances, forklifts) special vehicles, off-road vehicles, ATV and other vehicle lighting and mining field patrols and other special or mobile environment lighting etc. |
