Overview
Quick Details
- Place of Origin:
- Zhejiang, China
- Brand Name:
- WINSTON
- Model Number:
- Am8
- Usage:
- Position Sensor
- Theory:
- Optical Sensor
- Output:
- Analog Sensor
- Application:
- Detection
- Type:
- Waterproof
- Product name:
- explosion-proof switch
- Name:
- 2 Wires proximity switch
- Material:
- nickel-plated brass
- Certificate:
- CE
- Color:
- Silver
- Capacity:
- 100
- Warranty:
- 12 Months
- Protection grade:
- IP67
Packaging & Delivery
- Selling Units:
- Single item
- Single package size:
- 35X32X32 cm
- Single gross weight:
- 15.0 kg
- Package Type:
- Inner box and outer carton
- Picture Example:
![package-img]()
- Lead Time:
Quantity(Piece) 1 - 10 11 - 100 >100 Est. Time(days) 7 7 To be negotiated
Am8 WINSTON 2 Wires Nc Safety Explosion-Proof Proximity Switch
Other products
 | | |
| | |
* With low-voltage power supply, micro-current output, small volume and other advantages, Mamur sensors can be applied for special places with requirements of explosion proof.
Application
Technical data
| Model | Two-wire normally close , flush | AM8-3001LB |
| Two-wire normally close , non-flush | AM8-3002LB | |
| Specification | Rated Vollage | 8.2V |
| Sensing Range | 1mm | |
| Standard Object Q235 steel(mm) | 12*12*1t | |
| Oscillating /Stop Pscillating Current | ≥2.2mA/≤1mA | |
| load resistance | 1KΩ | |
| Switch frequency, Flush | 1.5Hz | |
| Shell material | Nickel-plated brass | |
| Protection Level | IP67 | |
| working environment temperature | -20ºC~70ºC | |
| External wiring diagram |
Dimension
