| 1. FM200 fire suppression system breif introduction: |
Fm200 is a clean extinguishing agent, which would completely vaporized in the air, and well insulated. Its total flooding mode is applicable to electric fire, liquid fire or fusible solid fire, solid surface fire, gas fire which gas supply is cut before extinguishing. And it is able to protect computer rooms, communication rooms,substation rooms, hi-tech device rooms, generator rooms, gasoline storerooms, combustible chemical storerooms, libraries, data rooms, archives, treasuries, etc. We manufacture fm200 system that is well structured, reliable, and widely applied to computer rooms, archives, program control exchange engine rooms , TV broadcast center, financial organizations and government departments.
| 2.fm200 fire suppression system main technical parameter: |
1 Storage of cylinder: 40L/70L/100L/120L/150L/180L
2 Storage Pressure: 2.5MPa/4.2MPa(20℃)
3 Maximum Working Pressure (50℃): 3.4MPa/5.3MPa
4 Operating Method: electromagnetic starter; emergency mechanical starter
5 Nitrogen pressure of the electromagnetic driving device: 6.0±1.0MPa (20℃)
6 Starter power of the electromagnetic driving device: DC24V/1.5A
7 Extinguishing agent filling density: ≤1150kg/m3
8 Extinguishing agent spurting time: ≤8s
9 Protective Area Temperature: 0℃~50℃
10 Cylinder spurting allowance: ≤2kg/bottle
11 Cylinder-room temperature requirement: -10℃~50℃
| 3.fm200 system main parts: |
Cylinder with valve,solenoid valve,gauge,diptube,high pressure flexible hose,pilot cylinder,manifold pipe,gas check valve,safety valve,pressure switch,gas check pipe,selector valve,flange,square elbow.
| 4.How to pack the hfc-227ea fire extinguishing system: |
Every parts use bubble bag wrap it,then use non fumigation wooden case packing it,good protect product.
