- Place of Origin:
- Zhejiang, China
- Brand Name:
- welfare
- Supply Ability:
- 5000 Set/Sets per Month
- Packaging Details
- standard export packing
- Port
- Shengzheng/Ningbo
Hot gas Aerosol Fire suppression system
| 1.Aerosol fire suppression system intoduction: |
1.Aerosol is one of environment friend fire suppression System, only produce: 67% Nitrogen, 30%CO2,and less 1% solid material, others are water,with advance of Non-corrosive, no toxic, resistant voltage and good insulation performance
2.Applicate to protect the following Areas:
Generator room, switch board room, power substation, common machine room
3.Including 3 parts:
1. Fire Extinguishing system
2. Fire detectors and alarms
3. Inside Aerosol Gas
| 2.Aerosol fire suppression system how to install: |
1. Suspended
2. Stand Floor
Full set Fire Suppression System = Equipment +Agent + Fire alarm and detector
| 3.Aerosol fire suppression system how to design: |
Equipment including:
Cabinet +Cylinder+Agent +Insulation layer +Ignitron + Refrigerant
Aerosol: Designed by the Room size and concentration, calculated by weight of the formula of design standard
Fire alarm and detector: decided by Protective area, number of the door, height of the room
Model: QRR5LW/S, QRR10LW/S, QRR20LW/S, QRR30LW/S
Discharge Time: Max 10S,
Max. Protect area “ 500 sqm, or 1600 Sqm
switch board room designed concentration 14%, every cbm use 0.14KG weight gas; engineer room designed concentration
13%,every cbm use agent 0.13KG;
| 4.Aerosol fire suppression system main technical: |
Solid contents of Aerosol : <1%
Insulation performance >200Ohm
Impact strength: 0
Maximum safety current and time :150mA/5min
Minium actuate time 250mA/5ms
Relative Humidity:≤95%
Model and Size and main specification:
Q5LTR: agent 5kg, Ohm 1~9 , cabinet size: 330*400*706, total weight 35kg
Q10LTR:agent 10kg, Ohm 1-9, cabinet size:330*640*700, total weight 50kg
Q20LTR: agent 20kg, Ohm 1-9, cabinet size:350*400*800, total weight 90kg
Q30LTR: agent 30kg , Ohm 1-9, cabinet size:330*620*1400, total weight120kg
