Emergency light yellow bulb
1.Main specification:
Wall or Ceiling mounted type
Voltage:220V/110V
Light source:2pcs lamp,5W each
Lead Acid Battery: 6A 4.5 AH
Emergency Duration: >90min
24Hours recaharge time, after 300 minutes discharging
Test Switch And charge Rate indicator
Low Voltage Batter Disconection
Products size 30.8*14*10.1CM
2.Packing details:
| QTY/CTN | N.W./CTN | G.W./CTN | CBM/CTN | CTN SIZE |
| 6pcs | 10.6kgs | 11.25kgs | 0.036m3 | 34*33.3*32cm |
3.Emergency light structure and mounting instruction:
Wall Mounting
1. Remove mounting plate from fixture by prying with screwdriver(See Fig.1)
2. Insert screwdriver to make appropriate keyhole slots open on mounting plate.
3. Pass blue(neutral) and either black 120V or red 277V hot,wire leads through center hole of mounting plate,make electrical connection in junction box, see electrical connection below.You may use hanging hook to hang fixture while making connection. Cap off unused hot lead.
4. Mount mounting plate to junction box with screw provided 8#32×1"long.
5. Connect red lead to battery positive terminal.(See Fig.2)
6. Snap on fixture to mounting plate.
7. Restore power and press test button.Bettery powered builds will come on. AC light will turn off.
Ceiling Mounting
1. Remove mounting plate from fixture by prying with screwdriver gently. (See Fig.1)
2. Open top cover and knockout on the top of fixture.
3. Secure the mounting plate to tube with nut.
4. Pass blue(neutral) and either black 120V or red 277V hot,wire leads through center hole of mounting plate,make electrical connection in junction box, see electrical connection below.You may use hanging hook to hang fixture while making connection. Cap off unused hot lead.
5. Connect red lead to battery positive terminal.(See Fig.2)
6. Snap on fixture to mounting plate.
Restore power and press test button.Bettery powered builds will come on. AC light will turn off.
