XL16B/F11L-12V-1 16mm IP67 12V LED Power symbol Latching push button switch with power symbol
Click on the image to view the original image
Product: views:4XL16B/F11L-12V-1 16mm IP67 12V LED Power symbol Latching push button switch with power symbol
Branch: Sunlight/OEM
Type: Push button switch
Size: 2X3X3 cm
Unit Price: Negotiated
Min.Order:
Supply:
Delivery: Shipment within days since the date of payment
Valid until: Long Term
Updated on: 2019-10-17 05:55
  Negotiated
Product Details
Overview
Quick Details
Place of Origin:
Zhejiang, China
Brand Name:
Sunlight/OEM
Model Number:
XL16B/F11L-12V-1
Protection Level:
IP67
Max. Current:
3A
Max. Voltage:
250VAC
Mounting hole diameter:
16mm
Terminal:
Solder Terminals
Led voltage:
12V
Type:
Push button switch
Material:
Aluminum
Operation type:
Self-locking
Lamp color:
RedGreenYellowBlueWhite
Product type:
Mini Push Button Swicth
Certificate:
CE RoHS SGS
Samples:
Available

Packaging & Delivery

Selling Units:
Single item
Single package size:
2X3X3 cm
Single gross weight:
0.025 kg
Picture Example:
package-img
Lead Time:
Quantity(Piece)1 - 1000>1000
Est. Time(days)7To be negotiated
Product Description

Feature

1)XL16B/F11L-12V-1 16mm IP65 12V LED Power symbol Latching push button switch with power symbol
2)16mm pin terminal
3)latching
4)CE RoHS SGS
5)anti-vandal

Application

It can be used in variety of places such as Outdoor controls, Communications,Security equipment,Defense,Medical equipment,Industrial automation,Food processing equipment,Security control button,Industrial machinary,Coffee maker control button,Transportation:Mass-transit,life trucks,Bathroom control button and so on.


Model number:

Momentary                                                                            Latching

Means that when you push switch and then move your finger, the actuator will back to the origina

Means that when you push switch once it will change state and stay in this pushed-down position and will not come back to original position unless you push it again.

Technical parameters:

Install diameter: 16mm

Rated voltage: 3a / 250 V

Shape: flat head

Function: interlocking (1no1nc)

LED type: illuminated power symbol

Color: blue (red, yellow, green, white)

Voltage: 12 V (2.8 A 250 V)

Terminal: Terminal pins

IP Classification: IP65 / 67

Bark material: black aluminum

Temperature: -40 to 75 degrees

Terminal description:

Detailed Images
Packing & Delivery

3-15 days lead time.

Certifications
FAQ

Q1: Are you a manufacturer?
A1:yes. We have 5 years export exprience.

Q2: Delivery time?
A2:Will send the goods out within 72 hours after the order confirmed.

Q3: After Sales Service?
A3: if u have any questions about the receuved product, we will try our best to solve it.

Q4: Return the goods?
A4: If the product really has quality problem, we will accept return the old one and send again.
