IP67 1000v dc 2.5mm2 ,4mm2 ,6mm2 25A 30A mc4 tyco solar cable connector
Click on the image to view the original image
Product: views:3IP67 1000v dc 2.5mm2 ,4mm2 ,6mm2 25A 30A mc4 tyco solar cable connector
Branch: sunlight/oem
Type: ADAPTER
Unit Price: Negotiated
Min.Order:
Supply:
Delivery: Shipment within days since the date of payment
Valid until: Long Term
Updated on: 2019-10-17 05:56
  Negotiated
Product Details
Overview
Quick Details
Place of Origin:
Zhejiang, China
Brand Name:
sunlight/oem
Model Number:
MC4 Panel Connector
Type:
ADAPTER
Application:
Solar energy system
Gender:
Male and female
Is_customized:
YES
Rated voltage:
DC 1000V
Test voltage:
6000V
Contact material:
Copper, silver plated
Insulation material:
PPO
Degree protection:
IP67
Suitable cable cross sections:
2.5/4/6mm sq
MOQ:
100sets
Flame:
UL94-VO&UL94-5VA

Packaging & Delivery

Selling Units:
Multiple of
Package size per batch:
54X26X22 cm
Gross weight per batch:
11.5 kg
Package Type:
Standard exporting cartons
Picture Example:
package-img
package-img
Lead Time:
Quantity(Pair)1 - 50000>50000
Est. Time(days)7To be negotiated

500pair=1000pcs

500 pair IP67 1000v dc 2.5mm2 ,4mm2 ,6mm2 16A 20A 25A 30A mc4 tyco solar connector mc4 to sae plug cable solar terminal

Product Description

-The advantages of Waterproof IP67 1000v dc 2.5mm2 ,4mm2 ,6mm2 16A 20A 25A 30A mc4 tyco solar connector mc4 to sae plug cable solar terminal

·Simple on-site processing



·Mating safety provided by keyed housings



·Mutiple plugging and unplugging cycles



·Accomodates PV cable with deferent insulation diamaters



·High current carrying capacity





·High quality



 -Specifications of Waterproof IP67 1000v dc 2.5mm2 ,4mm2 ,6mm2 16A 20A 25A 30A mc4 tyco solar connector mc4 to sae plug cable solar terminal


-The construction of  MC4



-Assembly Instructions of MC4



 1. During self assembly, parts and tools other than those stated by Sunlight electric are used or if the

    preparation and assembly instructions described here are disregarded then neither safety nor

    compliance with the technical data can be guaranteed.



2. For protection against electric shock,PV connectors must be isolated from the power supply while being

    assembled or disassembled.



3. The end product must provide protection from electric shock.



4. Unplugging under load: PV plug connections muct not be unplugged while under load. They can be placed

    in a no load state by switching off the DC/AC converter or breaking the AC circuit interrupter. Plugging

    and unplugging while under voltage is permitted.



5. Disconnected connectors should be protected from dirt and water with sealing caps.



6. Plugged parts are watertight IP67



-Assemble solar connector with cable

 1. Push the crimped contact into the socket resp. Plug insulator until it engages. Pull lightly on the lead to

    check that the metail part has engaged.



2. Screw on the cable gland, hand-tight, with the tools PV-STX,tightening torque about:2.2 Nm.





3. Mount the connector together until they engage. Check correct engagement by pulling on the coupling.

4. Compress the two snap-in springs by hand or with the PV STX tool and separate the coupling.
