  ZG3NC-260B SSR-60DA 3-32VDC to 24-240VAC 60a ssr solid state relay

    ZG3NC-260B SSR-60DA 3-32VDC to 24-240VAC 60a ssr solid state relay

  AC solid state raly can be divided into voltage zero-crossing conducting type(zero-crossing type for short) and random conducting type(random typer for short) by switching mode ; bidirectional controllable silicon output(normal type) and unidirectional controllable silicon antiparallel (strengthening type) by switch element ; Pin insert type (natural cooling, radiator unnecessary) on printed-wiring board and installing type(cooled by radiator) fixed on metal motherboard by installing mode; and wide scope input(DC3-32V) constant current type and tandem resistance limiting current type by input mode etc.

  ZG3NC-260B SSR-60DA 3-32VDC to 24-240VAC 60a ssr solid state relay

  Industrial automation installment, AC motor control, Intermediate relay,solenoid valve control, Numerical control machinery,external guidnance system,computer periphery connection, Illumination,stage lighting control, Electric stove,heating,warm control, street light,signal light,traffic light,Color photo enlargement, film processing equipment,injection machinery,automatic fire control and security system,etc.

  ZG3NC-260B SSR-60DA 3-32VDC to 24-240VAC 60a ssr solid state relay

  ZG3NC-260B SSR-60DA 3-32VDC to 24-240VAC 60a ssr solid state relay

  ZG3NC-260B SSR-60DA 3-32VDC to 24-240VAC 60a ssr solid state relay

  ZG3NC-260B SSR-60DA 3-32VDC to 24-240VAC 60a ssr solid state relay

When the current is up to 40A,the SSR must be installed with radiator.

The dimension of radiator:

1. Over-current and loading short circuit result in SSR permanent damage. Quick fuse is one of the over-current protection methods. Small capacity may also adopt fuse. Over-voltage protection adopts parallel connection metal oxide varistor (MOV) as well as RC absorbing return inside SSR. The area size of MOV determines the absorbing power. The thickness of MOV determines protective voltage value. Generally, 220V series SSR may choose varistor of 500-630 VDC, 380V series SSR may choose varistor of 700-900VDC.
2. If ambient temperature is too high, the loading capacity of SSR will descend. If the ambient temperature is high or the heat radiation is bad, the chosen SSR should be kept a certain margin.
3. The resistance load should not surpass 60% of rated current. The inductance load should not surpass 40% of rated current.

TNT: about 5-7 working days could reach your side normally

EMS: need 10-15 working days to reach your side

UPS: special express for North America,need 3-5 working days

DHL: normally 3-5 working days could reach your side

FEDEX: normally 3-10 working days could reach US and European

1.Reply inquiry in 24 hours.

2.Please kindly inform us which items you are interested & the reasonable price will be providedyou upon

   receipt of your new inquiry ASAP.

3.Answer your question detailed.

4.Solved the problem with you during using our products.

5.Welcome to visit to our company and technology communication.

  Yueqing Xianglang Electric Technology Co., Ltd is a professional manufacturer of industrial electrical

products in China.Our primary manufacturing facilities are located in Wenzhou, China.SSR and all

kinds of SSR with well-equipped testing equipment and strong technical force. With a wide

range, good quality, reasonable prices and stylish designs.

Q1: Are you a manufacturer?

A1:yes. We have 3 years export exprience.

Q2: Delivery time?

A2:Will send the goods out within 72 hours after the order confirmed.

Q3: After Sales Service?

A3: if u have any questions about the receuved product, we will try our best to solve it.

Q4: Return the goods?

A4: If the product really has quality problem, we will accept return the old one and send again.
