JGX-1A2410A SSR-10AA 10A 90-250VAC input 24-480VAC output single phase ssr relay solid state relay
Click on the image to view the original image
Product: views:4JGX-1A2410A SSR-10AA 10A 90-250VAC input 24-480VAC output single phase ssr relay solid state relay
Branch: Sunlight(XiangLang)/OEM
Type: Micro Relay
Size: 4X4X3 cm
Unit Price: Negotiated
Min.Order:
Supply:
Delivery: Shipment within days since the date of payment
Valid until: Long Term
Updated on: 2019-10-17 05:56
  Negotiated
Product Details
Overview
Quick Details
Place of Origin:
Zhejiang, China
Brand Name:
Sunlight(XiangLang)/OEM
Model Number:
JGX-1A2410A
Theory:
Solid State Relay
Usage:
General Purpose
Size:
Miniature
Protect Feature:
Sealed
Contact Load:
Low Power
Certifications:
CE/ISO9001/ROHS
Color:
Black
Input voltage:
90-250VAC
Output voltage:
24-280VAC
Output Current:
10A
Type:
Micro Relay
Product name:
Safety Relay
Contact material:
Silver Alloy
Indicator:
LED status indicator
Quality:
Reilable

Packaging & Delivery

Selling Units:
Single item
Single package size:
4X4X3 cm
Single gross weight:
0.115 kg
Picture Example:
package-img
Lead Time:
5

  JGX-1A2410A 10A 90-250VAC input 24-480VAC output single phase ssr relay solid state relay

Product Description



 Assortment of SSR

    JGX-1A2410A 10A 90-250VAC input 24-480VAC output single phase ssr relay solid state relay

  AC solid state raly can be divided into voltage zero-crossing conducting type(zero-crossing type for short) and random conducting type(random typer for short) by switching mode ; bidirectional controllable silicon output(normal type) and unidirectional controllable silicon antiparallel (strengthening type) by switch element ; Pin insert type (natural cooling, radiator unnecessary) on printed-wiring board and installing type(cooled by radiator) fixed on metal motherboard by installing mode; and wide scope input(DC3-32V) constant current type and tandem resistance limiting current type by input mode etc.





  Application

  JGX-1A2410A 10A 90-250VAC input 24-480VAC output single phase ssr relay solid state relay

  Industrial automation installment, AC motor control, Intermediate relay,solenoid valve control, Numerical control machinery,external guidnance system,computer periphery connection, Illumination,stage lighting control, Electric stove,heating,warm control, street light,signal light,traffic light,Color photo enlargement,film processing equipment,injection machinery,

Automatic fire control and security system,etc.





                       Technical Parameters

  JGX-1A2410A 10A 90-250VAC input 24-480VAC output single phase ssr relay solid state relay

JGX-1A4880A

Load Current10A
Load Voltage24-280VAC
Control Voltage90-250VAC
Control Current≤12mA
On Voltage≤1.5V
Off-state Leakage Current≤2mA
Time Off≤10ms
Dielectric Strength2500VAC
Insulation Resistance100MΩ/500VDC
Ambient Temperature-30~+75°C
Mountiong MethodsBolt
The work instructionsLED
Weight

90g(10A-40A) 105g(above 40A)



TypeInput VoltageOutput VoltageOutput Current (A)
JGX-1A2410A90-250VAC24-240VAC10
JGX-1A2416A90-250VAC24-240VAC16
JGX-1A2440A90-250VAC24-240VAC40
JGX-1A2460A90-250VAC24-240VAC60
JGX-1A2480A90-250VAC24-240VAC80
JGX-1A24100A90-250VAC24-240VAC100
JGX-1A4810A90-250VAC24-480VAC10
JGX-1A4816A90-250VAC24-480VAC16
JGX-1A4825A90-250VAC24-480VAC25
JGX-1A4840A90-250VAC24-480VAC40
JGX-1A4860A90-250VAC24-480VAC60
JGX-1A4880A90-250VAC24-480VAC80
JGX-1D2410A3-32VDC24-240VAC10
JGX-1D2416A3-32VDC24-240VAC16
JGX-1D2425A3-32VDC24-240VAC25
JGX-1D2440A3-32VDC24-240VAC40
JGX-1D2460A3-32VDC24-240VAC60
JGX-1D2480A3-32VDC24-240VAC80
JGX-1D24100A3-32VDC24-240VAC100
JGX-1D4810A 3-32VDC24-480VAC10
JGX-1D4816A 3-32VDC24-480VAC16
JGX-1D4825A3-32VDC24-480VAC25
JGX-1D4840A3-32VDC24-480VAC40
JGX-1D4860A3-32VDC24-480VAC60
JGX-1D4880A3-32VDC24-480VAC80
JGX-1D48100A3-32VDC24-480VAC100
JGX-1DD0610A3-32VDC5-60VDC10
JGX-1DD0616A3-32VDC5-60VDC16
JGX-1DD0625A3-32VDC5-60VDC25
JGX-1DD0640A3-32VDC5-60VDC40
JGX-1DD0660A3-32VDC5-60VDC60





    Wiring and Dimension

  JGX-1A2410A 10A 90-250VAC input 24-480VAC output single phase ssr relay solid state relay





            Pictures

  JGX-1A2410A 10A 90-250VAC input 24-480VAC output single phase ssr relay solid state relay





                              Cautions while using the SSR

  JGX-1A2410A 10A 90-250VAC input 24-480VAC output single phase ssr relay solid state relay

When the current is up to 40A,the SSR must be installed with radiator.

The dimension of radiator:

1. Over-current and loading short circuit result in SSR permanent damage. Quick fuse is one of the over-current protection methods. Small capacity may also adopt fuse. Over-voltage protection adopts parallel connection metal oxide varistor (MOV) as well as RC absorbing return inside SSR. The area size of MOV determines the absorbing power. The thickness of MOV determines protective voltage value. Generally, 220V series SSR may choose varistor of 500-630 VDC, 380V series SSR may choose varistor of 700-900VDC.
2. If ambient temperature is too high, the loading capacity of SSR will descend. If the ambient temperature is high or the heat radiation is bad, the chosen SSR should be kept a certain margin.
3. The resistance load should not surpass 60% of rated current. The inductance load should not surpass 40% of rated current.
