Click on the image to view the original image
- Type:
- Aviation Obstruction Lights
- Input Voltage(V):
- 12V
- Lamp Power(W):
- 150
- Lamp Luminous Flux(lm):
- 100%
- Lamp Luminous Efficiency(lm/w):
- 50
- CRI (Ra):
- 80
- Color Temperature(CCT):
- RD
- Beam Angle(°):
- 360 Horizontal Beam Angle
- IP Rating:
- IP68
- Certification:
- CE
- Emitting Color:
- Red
- Lamp Body Material:
- PC
- Base Type:
- E27
- Light Source:
- LED
- Place of Origin:
- China
- Brand Name:
- XINHANG
- Model Number:
- XH10
Packaging & Delivery
- Selling Units:
- Single item
- Single package size:
- 30X30X30 cm
- Single gross weight:
- 2.0 kg
- Picture Example:
![package-img]()
- Lead Time:
- 2
IP68 LED solar marine navigation light and boat light for buoy offshore navigation lantern
Features
- Normal range up to 12.5 nautical miles
- Strong-ray set up to 6000cd
- When the flash duration of 0.5 seconds for the time being in force for the light 4285cd, with a range of 12.5 nautical miles (T =0.74)
- Lamp base: made from marine die-casting aluminum alloy-----excellent resistance to corrosion
- Low power leads to huge savings on electricity
- Color Available in red, white, yellow, green
- Photoelectric conversion efficiency up to 50cd/W
- Biult-in GPS module synchronization can be multi-the-air synchronization of lights flash
- Built-in GSM/VHF communications module (RTU) could be used for remote monitorig terminal
Specifications
| Operating voltage | 12V (10V-30V) |
| Daylight switch | 300Lux+50Lux |
| Light quality | IALA256 |
| Optical/electrical conversion efficiency | >50cd/w |
| Dark current | <5mA |
| Divergence angle | 2.5° (In line with international standards IALA) |
| horizontal light distribution uniformity | >90% |
| Serial communication | RS232/RS485 |
| Lens material | UV plexiglass |
| Base material | die-casting aluminum alloy |
| Operating temperature | -30℃~+70℃ |
| Relative humidity | 100% (condensed) |
| Protection level | IP68 |
Packaging & Delivery
Packaging Details: 1 piece carton: 30*30*31 (cm)/2.5kg
4 pieces carton:60*60*30(cm)/10kg
Delivery Detail: 6-15 days after payment
Applications:
--High-rise building marking
--Telecom towers marking
--Road obstruction marking
--Marine navigation marking
--Port, beacon and dock walkway and entrance
