Click on the image to view the original image
- Input Voltage(V):
- AC100-240V 50/60Hz
- Lamp Luminous Flux(lm):
- 12000
- CRI (Ra>):
- 70
- Working Temperature(℃):
- -35 - 45
- Working Lifetime(Hour):
- 36000
- Lamp Body Material:
- ADC12
- IP Rating:
- IP65
- Certification:
- CE, CQC, RoHS
- Place of Origin:
- Jiangsu, China
- Brand Name:
- AN
- Model Number:
- SWP-JY100W
- Application:
- WAREHOUSE
- Light Source:
- LED
- Driver:
- FACTORY/Non-isolated
- LED Chip:
- 1W 2835 Epistar5000K 70+SANAN2235*2
- PF>:
- 0.92
- Beam angle:
- 60°/90°/110°
- Lumen Efficacy(Lm/w):
- 150
- Material:
- ADC12/AL1060PC
- UGR<:
- 22
- IP Grade:
- IP65
- Life span(H):
- 36000
- CCT(K):
- 3000/4000/5000/5700
- Warranty(Years):
- 5
Packaging & Delivery
- Selling Units:
- Single item
- Single package size:
- 33X33X18.5 cm
- Single gross weight:
- 1.75 kg
- Package Type:
- Packed in pearl cotton and cartons.
- Picture Example:
![package-img]()
![package-img]()
- Lead Time:
Quantity(Piece) 1 - 500 >500 Est. Time(days) 30 To be negotiated
Radar Sensors
With radar, microwave and infrared sensing optional.
Distribution Curve Flux
Multiple beam angles are available.
Explosive View
The explosive view shows every detail and the technology of the light.
Product Dimension(mm)
The dimension of different power lights as shown.
Installation Process
Multiple installation methods are available.
Package
Packed with paper card and pearl wool.
Company Profile
ALC was founded in Baoshan, Shanghai in 2008, In 2008-2014, our product is Negative ion air purifying energy-saving lamp, the number of single product production and sales is No.1 in China, the main sales markets are Europe and the United States. In 2014, ALC invested a production base in Jianhu, Yancheng, Jiangsu, with an available production area of over 6,000 square meters. In 2014-2016, ALC began productionmk of LED indoor lighting products. The main products are LED bulbs, LED downlights, LED aluminum-plastic T8 lamps. And we successfully obtained orders fro various government tender projects in Egypt. In 2017, ALC began to transform to LED lamps. OEM ,ODM services are available. The company has complete performance testing equipment for photoelectric and structural. We sincerely welcome friends at home and abroad to come to our company to negotiate.
