- Light Source:
- LED
- Input Voltage(V):
- AC100-250V
- Lamp Luminous Flux(lm):
- 22000
- CRI (Ra>):
- 70
- Working Temperature(℃):
- -20 - 50
- Working Lifetime(Hour):
- 50000
- IP Rating:
- IP65
- Certification:
- CE, RoHS
- Warranty(Year):
- 5
- Place of Origin:
- Jiangsu, China
- Brand Name:
- AN
- Model Number:
- ASLS01-200W
- Beam Angle(°):
- 60*126°
- Application:
- ROAD
- Color:
- Light Grey, Grey
- Power Supply:
- AC
- Driver:
- DC driver
- LED Chip:
- SMD3030
- PF>:
- 0.95
- Beam angle:
- 60*126°
- Lumen Efficacy(Lm/w):
- 110
- Material:
- tensile aluminum
- IP Grade:
- IP65
- Life span(H):
- 50000
- CCT(K):
- 3000/4000/5700
- Dimension(mm):
- 507*242*102
Packaging & Delivery
- Selling Units:
- Single item
- Single package size:
- 52X26X12 cm
- Single gross weight:
- 5.0 kg
- Package Type:
- Packed in pearl cotton and cartons.
- Lead Time:
Quantity(Piece) 1 - 500 >500 Est. Time(days) 15 To be negotiated
Product Features
LUMINOUS EFFICIENCY: 110LM/W;
LHIGH QUALITY A1070 TENSILE ALUMINUM HEAT SINK WITH GOOD HEAT CONDUCTION AND HEAT DISSIPATION PERFORMANCE;
CONSTANT CURRENT LED DRIVE POWER;
IP65 PROTECTION;
NOVEL AND SIMPLE APPEARANCE, HIGH COST PERFORMANCE.
Distribution Curve Flux
The beam angle is 60*126°
Explosive View
The explosive view shows every detail and the technology of the light.
Product Dimension(mm)
The dimension of different power lights as shown.
Technical Specification | |||
Model | 100W | 150W | 200W |
Input Voltage /Frequency | AC100-250V 50/60Hz | ||
Power Factor | ≥0.95 | ||
Drive Output Voltage | 48 | ||
Drive Output Current | 1.9A | 2.8A | 1.9Ax2 |
Drive Type | DCdriver | ||
Surge Protection | 6KV with External SPD | ||
LED Brand / Model | SMD3030 | ||
LED Qty(pcs) | 120 | 160 | 220 |
Luminous Flux(Lm) | 11500 | 16500 | 22000 |
LuminousEfficiency(Lm/W) | 110 | 110 | 110 |
Beam angle(°) | 60x126 | ||
CRI | >70 | ||
IP Rate | IP65 | ||
Operating Ambient Temperature(℃) | ﹣20 ~ ﹢50 | ||
Product Size(mm) | L340 * W242 * H102 | L400 * W242 * H102 | L507* W242 * H102 |
Package
Packed with pearl wool and carton.
