high bay led light 150 20000Lm 130LmW Good thermal performance Safety protection for Warehouses Factories Supermarkets Stadiums

Click on the image to view the original image

Product：	views：4high bay led light 150 20000Lm 130LmW Good thermal performance Safety protection for Warehouses Factories Supermarkets Stadiums
Branch：	AN
Size：	38X38X19 cm
Unit Price：	Negotiated
Min.Order：
Supply：
Delivery：	Shipment within days since the date of payment
Valid until：	Long Term
Updated on：	2019-11-19 18:36

Product Details

Overview

Quick Details

Input Voltage(V):: AC100-240V 50/60Hz

Lamp Luminous Flux(lm):: 20000Lm±10%

CRI (Ra>):: 70

Working Temperature(℃):: -35 - 45

Working Lifetime(Hour):: 36000

Lamp Body Material:: ADC12/AL1060/PC

IP Rating:: IP65

Certification:: CE, RoHS

Place of Origin:: Jiangsu, China

Brand Name:: AN

Model Number:: SWP-JY150W/LM

Application:: Theme Park

Light Source:: LED

Driver:: 150W FACTORY Non-isolatedcircular waterproof driver CE

LED Chip:: 2835 5000K

PF>:: 0.92

Beam angle:: 90°/110°

Lumen Efficacy(Lm/w):: 130

Material:: ADC12

UGR<:: 22

IP Grade:: IP65

CCT(K):: 3000/4000/5000/5700

Warranty(Years):: 5

Packaging & Delivery

Selling Units:: Single item

Single package size:: 38X38X19 cm

Single gross weight:: 3.5 kg

Package Type:: Packed in pearl cotton and cartons.

Lead Time:

Quantity(Piece)	1 - 2	>2
Est. Time(days)	15	To be negotiated

Product Description

Product Features

Simple and beautiful appearance, easy to clean and maintain;

Hexagonal honeycomb reflective cup, uniform light, no yellow spots;

The radar sensors can be put in the central as optional(5-8m, 150°);

Light efficiency 120Lm/W(power version)/150Lm/W(lumen version);

Non-isolated power supply/linear power supply;

60°/90°/110°;

UGR≤22

Distribution Curve Flux

Multiple beam angles are available.

Product Dimension(mm)

The dimension of different power lights as shown.

Product Specifications
odel No.	SWP-JY75W/LM	SWP-JY115W/LM	SWP-JY150W/LM	SWP-JY185W/LM
Power	75W±10%	115W±10%	150W±10%	185W±10%
Lumens	10000Lm±10%	15000Lm±10%	20000Lm±10%	25000Lm±10%
LED	SMD2835/3030 (120pcs)	SMD2835/3030 (192pcs)	SMD2835/3030 (288pcs)	SMD2835/3030 (336pcs)
Power Supply	FACTORY
Voltage	100V-240Vac 50/60Hz
Luminous Efficiency	130/150Lm/W
CRI	≥70
UGR	UGR<22
CCT	3000K/4000K/5000K/5700K
PF	≥0.92
Beam angle	90°/110°
Material	ADC12/AL1060/PC
Life Span	≥36000H L70B50
IP Grade	IP65
Operating Temperature	-35℃ - 45℃
Net Weight(Kg)	1.75Kg	2.1Kg	3.1Kg	3.4Kg
Gross Weight(Kg)	2.0Kg	2.5Kg	3.5Kg	4.0Kg

Installation Process

Multiple installation methods are available.

Package

Packed with PE pet and carton.

About us

Company Profile

ALC was founded in Baoshan, Shanghai in 2008, In 2008-2014, our product is Negative ion air purifying energy-saving lamp, the number of single product production and sales is No.1 in China, the main sales markets are Europe and the United States. In 2014, ALC invested a production base in Jianhu, Yancheng, Jiangsu, with an available production area of over 6,000 square meters. In 2014-2016, ALC began productionmk of LED indoor lighting products. The main products are LED bulbs, LED downlights, LED aluminum-plastic T8 lamps. And we successfully obtained orders fro various government tender projects in Egypt. In 2017, ALC began to transform to LED lamps. OEM ,ODM services are available. The company has complete performance testing equipment for photoelectric and structural. We sincerely welcome friends at home and abroad to come to our company to negotiate.

Production Process

Application
