- Support Dimmer:
- No
- Place of Origin:
- Jiangsu, China
- Brand Name:
- AN
- Rated Power:
- 8W
- Voltage:
- AC175-265V, AC175-265V
- Wattage:
- 8W/12W
- Base:
- B22/E27
- P.F>:
- 0.5
- Life Span(hours):
- 25000
- Packing type:
- color box
- Length(mm):
- 120
- Width(mm):
- 60
- Units per carton:
- 100
- MOQ:
- 1000
Packaging & Delivery
- Selling Units:
- Single item
- Single package size:
- 6.2X6.2X14 cm
- Single gross weight:
- 0.08 kg
- Package Type:
- packed in color box and carton
- Lead Time:
Quantity(Piece) 1 - 2000 >2000 Est. Time(days) 15 To be negotiated
Product Features
LOW-WAVELENGTH LED CHIP,LIFE IS LONGER THAN
TRADITIONAL BLACK LIGHT TUNGSTEN LAMPS AND BLACK LIGHT ENERGY-SAVING LAMPS,AND MORE UNIFORM UV OUTPUT;
27/E26, B22 BASES ARE AVAILABLE. AC85-265V INPUT;
GLASS COVER WITH LONG LIFE AND GREAT LUMINOUS EFFECT;
THE PRODUCT USES CONSTANT CURRENT DRIVER FOR LONGER LIFE, UP TO 25,000 HOURS;
THE PRODUCT USES ANTI-UV BLACK PBT SHELL, WHICH CAN EFFECTIVELY PREVENT THE PRODUCT FROM EMITTING ULTRAVIOLET RAYS TO DAMAGE THE LAMP BODY PLASTIC;
PRODUCTS OF VARIOUS POWERS CAN BE CUSTOMIZED. LED CHIPS OF 365NM OR 395NM WAVELENGTH CAN BE SELECTED;
THE BEAM ANGLE CAN REACH TO 270°
Spectroradiometric Parameters
Spectroradiometric Parameters as shown.
Technical Specification | ||
Model | 8W | 12W |
Input Voltage /Frequency(V/Hz) | AC175-265V 50/60Hz | |
Input Current(mA) | 70 | 115 |
Power Factor | ≥0.5 | |
Drive Output Voltage(V) | 60 | 90 |
Drive Output Current(mA) | 120 | 120 |
Drive Type | DCdriver | |
Surge Protection(V) | 1KV with External SPD | |
Hi-Pot/Insulation Resistance Test | 1500 | |
Isolation Level | Class Ⅱ | |
LED Brand / Model | SMD2835 | |
Wave Band | 395nm | 395nm |
LED Qty(pcs) | 20 | 30 |
Beam angle(°) | 270 | |
CRI | >70 | |
IP Rate | IP20 | |
Rated Life Span(Hours) | >25000 | |
Switch Times(times) | 15000 | |
Dimmable | Optional | |
Product Size | Ø60x118 | Ø60x118 |
Application
INSTEAD OF THE TRADITIONAL BLB(BLACK LIGHT BULB), CAN BE USED FOR STAGE LIGHTING, INDOOR MOSQUITO-LURED LAMP, FARM BREEDING AND TRAPING, ETC.
