* Working with Ni-Cd/Ni-MH battery packs.
* DC constant current output at emergency mode.
* Over-discharge protection
* Additional relay that can control LED driver.
* Accord with IEC61347, EN55015, EN60598-2-22.
| * Input (Charging) | |
| Rated supply voltage | 220-240V |
| Mains frequency | 50-60Hz |
| Mains current | <80mA |
| Rated power | 6W max. |
| Charge current | 0-200mA Nominal |
| Battery charge time | ≥24HRS |
| Leakage current (PE) | <0.5mA |
| Ambient temperature ta. | 0......+50℃ |
| Max. casing temperature tc. | 70℃ |
| * Output (Discharging) | |
| Output voltage | DC10......72V max. |
| Output current | Constant current 25-150mA |
| Current stability | ± 5% |
| Output power | 6W max. |
| Discharge time | 1 hour/ 3 hours |
| Deep discharge protection voltage | 1.2V/cell |
| * Battery | |
| Battery pack | Ni-Cd battery |
| Max short temperature | 70℃ |
| Battery type | SC,C,D |
| Ambient temperature ta. | 0......+50℃ |
This product must be disconnected before the circuit on which it is installed is subjected to any high voltage or insulation resistance testing. Unrepairable damage will occur if this instruction is not followed.
YIHUI lighting Co., Ltd was founded in Baoan district of Shenzhen in 2011, is a professional emergency conversion kit manufacturer with our own brand “STREAMER ”.
Until now, YIHUI covers an area of more than 1500 square meters workshop and warehouse , 4 production lines , and advanced production equipments with annual production of 1,000,000 pcs kits. Since the founding of the company, YIHUI built an experienced engineer team from the very beginning to fully provide various emergency solution to meet customer’s needs.
- Packaging Details: Inner packing---White box for inner packing.
Outer packing---126 sets per carton.
- Delivery Time: Shipped in 20 days after payment.
