- Working with battery packs LiFePO4 6.4V 1500mAH.
- DC constant power output at Emergency Mode.
- Over-discharge protection.
- Additional relay that can control LED driver.
- Our product complied with UL924 standard.
* Input ( Charging )
Rated supply voltage 120-277V
Mains frequency 50-60Hz
Mains current < 50mA
Rated power < 4W
Charge current 0......300mA
Battery charge time 24 HRS
Leakage current (PE) < 0.5mA
Ambient temperature ta. 10......+50℃
Max. casing temperature tc. 70 ℃
* Output ( Discharging )
Output voltage DC 10......60V
Output current Constant power 50-500mA
Current stability ± 5%
Output power 4W ± 0.2W
Discharge time ≥ 1.5 HRS
Deep discharge protection voltage 4.7-5.1V
* Battery
Battery pack LiFePO4 IRF18650 6.4V 1500mAH
Max. short temperature 70℃
Battery type 18650
Ambient temperature ta. 10......+50℃
