Click on the image to view the original image
- Place of Origin:
- Shanghai, China
- Brand Name:
- Shangkai, Shangkai
- Model Number:
- JL
- Application:
- Home Kitchen
- Temperature of Media:
- Medium Temperature
- Power:
- Solenoid
- Media:
- Water
- Port Size:
- 1/4 6mm, 3/8 9mm
- Structure:
- Shutoff
- Standard or Nonstandard:
- Standard
- name:
- JL
- Certification:
- CQC, RoHS
- Crust Material:
- Plastic
- Ambient temperature:
- -25℃~+55℃
- ROHS/Sanitation grade:
- Comply with ROHS
- Max.Medium Temperature:
- 90℃
- Body material:
- POM
- Type:
- Normal Colse
- Supply Ability:
- 10000000 Piece/Pieces per Week of 12v high frequency 220v 50hz inlet water solenoid valve
- Packaging Details
- normal closedJL003 inlet water solenoid valve of
128 pieces in one Standard export carton , water solenoid valve .
- Port
- Shanghai
- Picture Example:
![package-img]()
- Lead Time:
Quantity(Pieces) 1 - 2000 >2000 Est. Time(days) 30 To be negotiated
Straight type 12VDC 10 bar normal close T55 JL006 G1/4 solenoid valve
| Principle | Straight type,Pilot type |
| Rating voltage | 12VDC,24VDC,110VAC/50H2,200-240VAC/50HZ |
| Type | Normal close |
| Medium | water |
| Pressure range | 0.02-0.8 MPa(0.2-8 bar)/0.02-1.0 MPa(0.2-10 bar) (Customizable) |
| Ambient Temp | -25—55°C |
| Max. medium Temp | 90°C |
| lnsulation class | Class "B"(130℃) / "F" (155℃ )/"H"(180℃) |
| Duty cycle | 100% at 25°C(for medium Temp.);lntermittent operation at 90C (for medium Temp.) |
| ROHS/Sanitation grade | According with ROHSAccording with FDA & drinking water quality for The material of touching the medium |
| Port size/amounting | G1/4 solenoid connector |
| Installation type | Use screw to fix the 4 holes on the top panel |
| Other | Customizable |
Shanghai Yongxing Electronic Switch CO.,Ltd,founded in 1985.We provide: button switches,ship type switches,seesaw switches,connecting terminals,micro-switches,refrigeraror door switches,small-size toggle witches,indicator lights,fuse holders,junction boxes and buzzers and there are more than 4,000 kinds of derived productions.The productions are widely applied to various fields such as electronics,electrical appliance and instruments,communication,audio and video,household appliances and medical equipment.
Our quality policy is:"Make progress by Technology,Create Brand by Quality".You have seen our successful past and we are striving to achieve what you expect.Let us go hand in hand and make sincere cooperation for a glorious future.
It has passed the certification of ISO9001:2008 Quality Management System and many of its products have passed the quality certification of authoritative certification bodies such as CQC,UL and ENEC,CE,ROHS.
Q1: Why choose your company?
A1:(1) We have all kinds of customized products with professional and exquisite.
(2) Any inquiries will be replied within 24 hours. Our sales team will try our best to support you.
(3) We strictly control every detail of production, and every product is inspected 100% by our QC team before delivery.Moreover, our production is abided by ISO9001,CQC, CE, UL, RoHS, ENEC and so on.
Q2: What’s the advantages of your company?
A2:(1) 30-year experience in manufacturer switches, more than 10-year experience on export.
(2) We design goods for the company of Extron, Midea, Philips, Povos and so on.
(3) Original manufacturer with direct factory price, Competitive & Fashionable
(4) Safe payment terms: T/T
(5) We offer EXW, FOB, CIF, etc.
(6) OEM available, Customers" designs are warmly welcome.
Q3:What’s your mainly products?
A3:We Produce and sell high quality electronic switches, more than 20 categories, including pushbutton switches, rocker switches, rotary switches, key lock switches, dip switches, slide switches, refrigerator switches, micro and mini switches, indicators,buzzes, terminal blocks, solenoid valves and so on.
Q4:How do I know that you have sent the products out?
A4:Once the products are sent out, a tracking number will be provided so that you can check where your goods at all times.
Q5:How you will send the goods to us?
A5:For urgent orders, we will send to your door by air. For bulk orders, it’s a good way send to you by sea but will take much time. For small orders, express will be best. We can send the goods to you by DHL, FEDEX, UPS, EMS etc
Send your inquiry Detail in the Below for free samples,Click “Send” NOW
