Home > Products > AD16 series big square SP no-locking blue cap push button switch with lamp
AD16 series big square SP no-locking blue cap push button switch with lamp
Click on the image to view the original image
Product： views：3AD16 series big square SP no-locking blue cap push button switch with lamp
Branch： SK(Shiningkey)
Unit Price： Negotiated
Min.Order：
Supply：
Delivery： Shipment within days since the date of payment
Valid until： Long Term
Updated on： 2019-11-19 20:35
  Negotiated
Product Details
Overview
Quick Details
Place of Origin:
Shanghai, China
Brand Name:
SK(Shiningkey)
Model Number:
AD16
Protection Level:
IP40
Max. Current:
3A
Max. Voltage:
250V AC
name:
Shanghai Yongxing AD series
certification:
CQC, CE
lamp voltage:
6V, 12V, 24V, 110VAC, 220VAC
Cap colors:
red, green , yellow, white, blue, orange , black
Operating temperature:
-5℃~+75℃
pole:
SP
Dielectric Strength:
1500V
Contact Resistance::
≤50mΩ
Insulation Resistance::
≥100MΩ
Protection Level::
IP40
Supply Ability
Supply Ability:
10000000 Piece/Pieces per Week
Packaging & Delivery
Packaging Details
50 pieces in one box, 2000 pieces in one Standard export carton for small light 6 pin waterproof latching switchpush button switch
Port
shanghai
Picture Example:
package-img
Lead Time:
Quantity(Pieces)1 - 3000 >3000
Est. Time(days)20To be negotiated
