Overview
Quick Details
- Place of Origin:
- Shanghai, China
- Brand Name:
- SK
- Model Number:
- KCD3-11
- Max. Current:
- 6A/10A
- Max. Voltage:
- 250V
- Mechanical Life:
- 100,000 cycles
- Certificate:
- CQC CE UL ENEC ROHS
- Contact Resistance:
- ≤50mΩ
- Insulation Resistance:
- ≥1,000MΩ
- Dielectric Resistance:
- 1,500V AC , 1 min
- Electronic life:
- 10,000 cycles
- Function:
- SPST
- Pins:
- 2
Supply Ability
- Supply Ability:
- 1000000 Piece/Pieces per Month
Packaging & Delivery
- Packaging Details
- 100 pcs in one bag and then put into master carton
- Port
- Shanghai
- Lead Time:
Quantity(Pieces) 1 - 30 >30 Est. Time(days) 20 To be negotiated
